Chapter 12 Use the LCD Panel
* This section is applicable to NAS models with LCD panel only.
The NAS provides a handy LCD panel for you to perform disk configuration and view
the system information.
When the NAS is started up, you will be able to view the server name and IP
address:
N
A
S
5 F 4 D
E 3
1 6 9 . 2 5 4 . 1 0
0
.
1
0
0
For the first time installation, the LCD panel shows the number of hard drives
detected and the IP address. You may select to configure the hard drives.
Number of
hard drives
detected
Default disk
configuration
Available disk configuration options*
1 Single Single
2 RAID 1 Single -> JBOD ->RAID 0 -> RAID 1
3 RAID 5 Single -> JBOD -> RAID 0 -> RAID 5
4 or above RAID 5
Single ->JBOD -> RAID 0 -> RAID 5
-> RAID 6
*Press the “Select” button to choose the option, and press the “Enter” button to
confirm.
