QUANTA QuantaGrid S31A-1U User Manual

BMC CONFIGURATION GROUP
3-45
8. In the Event Data 2 Configuration section,
 Event Data 2 AND Mask field is similar to Event Data 1 AND Mask.
 Event Data 2 Compare 1 & Event Data 2 Compare 2 fields are similar to Event Data
1 Compare 1 and Event Data 1 Compare 2 respectively.
9. In the Event Data 3 Configuration section,
 Event Data 3 AND Mask field is similar to Event Data 1 AND Mask.
 Event Data 3 Compare 1 & Event Data 3 Compare 2 fields are similar to Event Data
1 Compare 1 and Event Data 1 Compare 2 respectively.
10. Click on Add to save the modification and return to Event filter list.
11. Click on Cancel to cancel the modification and return to Event filter list.
12. In the Event filter list, select the configured slot and click Modify or alternatively
double click the configured slot to modify the existing event filter entry.
13. In the Event filter list, click Delete to delete the existing filter.
Alert Policy Tab
This page is used to configure the Alert Policy and LAN destination. You can add, delete or
modify an entry in this page.
Figure 3-27. PEF Management – Alert Policy
The fields of the PEF Management – Alert Policy Tabs are explained below.
Note:
Value ranges from 0 to 255.
