Quantech QTC4 STYLE A Series User Manual

SECTION 5 - TECHNICAL DATA
QUANTECH
67
FORM QTC4-NM1
ISSUE DATE: 4/2/2018
5
ALL DIMENSIONS - INCHES (MM)
QTC4
A,B C D
E
NOZZLE
SIZE
WATER
VOLUME.
GALLONS
(LITERS)
MINIMUM
CHILLED
WATER FLOW
RATE
GPM (L/S)
MAXIMUM
CHILLED
WATER FLOW
RATE
GPM (L/S)
MODEL
COND.
400 P
23.3
(592)
252.5
(6414)
83.5
(2121)
10
147
(556)
1090
(69)
3420
(215)
405 S
22.5
(572)
164.6
(4181)
83.8
(2129)
10
130
(492)
940
(59)
3420
(215)
410 H
22.5
(572)
252.6
(6416)
83.8
(2129)
10
130
(492)
940
(59)
3420
(215)
410 P
23.3
(592)
296.5
(7531)
83.5
(2121)
10
147
(556)
1090
(69)
3420
(215)
450 S
22.3
(566)
287.1
(7292)
94.2
(2393)
10
96
(363)
840
(53)
3320
(209)
490 H
23.3
(592)
308.4
(7833)
71.5
(1816)
10
147
(556)
1090
(69)
3420
(215)
460 S
22.3
(566)
331.2
(8412)
94.2
(2393)
10
96
(363)
840
(53)
3320
(209)
470 C
22.5
(571)
176.5
(4482)
71.7
(1820)
10
130
(492)
940
(59)
3420
(215)
480 C
23.3
(592)
176.2
(4475)
71.5
(1816)
10
147
(556)
1090
(69)
3420
(215)
500 S
23.3
(592)
308.4
(7833)
71.5
(1816)
10
147
(556)
1090
(69)
3420
(215)
TABLE 7 - OPTIONAL ONE-PASS EVAPORATOR (CONT'D)
NOTE: Minimum Chilled Water Flow Rate is for full load selections; Variable Primary Flow ratings as low as 50% of the minimum are permitted.
Glycol limits are higher. Please contact your Quantech Sales Representative for ratings and further information.
