FORM QWC3-NM1
ISSUE DATE: 11/20/2020
SECTION 5 – TECHNICAL DATA
QUANTECH
100
FOR UNITS WITH ALL POINT LOADS LESS THAN 1404 LBS (637 KG)
Weight Range (lbs) Weight Range (kg) Model Number Color
239 to 384 lbs 108 to 174 kg CIP-B- Red
384 to 639 lbs 174 to 290 kg CIP-B- White
639 to 851 lbs 290 to 386 kg CIP-B- Blue
851 to 1064 lbs 386 to 483 kg CIP-B- Gray
1064 to 1404 lbs 483 to 637 kg CIP-B- Black
FOR UNITS WITH ANY POINT LOAD ABOVE 1404 LBS (637 KG)
Weight Range (lbs) Weight Range (kg) Model Number Color
Up to 851 lbs Up to 386 kg CIP-C- Black
851 to 1149 lbs 386 to 521 kg CIP-C- Yellow
1149 to 1489 lbs 521 to 675 kg CIP-C- Black
1489 to 1786 lbs 675 to 910 kg CIP-C- Yellow w/ Red
1786 to 2028 lbs 910 to 920 kg CIP-C- Yellow w/ Green
2028 to 2254 lbs 920 to 1022 kg CIP-C- Red w/ Red
2254 to 2936 lbs 1022 to 1332 kg CIP-C- Red w/ Green
¡
ONE INCH DEFLECTION SPRING ISOLATORS CROSS-REFERENCE
Units shipped before June 15, 2008
