OPERATIONAL LIMITATIONS
TABLE 3 - TEMPERATURES AND FLOWS
DESIGN PARAMETERS - STANDARD EFFICIENCY (SE)
MODEL
EVAPORATOR
FLOW -
GPM (LPS)
CONDENSER
FLOW -
GPM (LPS)
LEAVING EVAP.
WATER TEMP. -
°F (°C)
ENT.
COND.
WATER
TEMP. -
°F (°C)
LVG.
COND.
WATER
TEMP. -
°F (°C)
EQUIPMENT
ROOM TEMP. -
°F (°C)
MIN MAX MIN MAX MIN
1
MAX
2
MIN MAX MIN MAX
050TSE 60 (3.8) 285 (18.0) 90 (5.7) 360 (22.7) 40 (4.4) 50 (10) 65 (18) 130 (54) 40 (4.4) 115 (46)
060TSE 60 (3.8) 285 (18.0) 90 (5.7) 360 (22.7) 40 (4.4) 50 (10) 65 (18) 130 (54) 40 (4.4) 115 (46)
070TSE 60 (3.8) 285 (18.0) 90 (5.7) 360 (22.7) 40 (4.4) 50 (10) 65 (18) 130 (54) 40 (4.4) 115 (46)
080TSE 60 (3.8) 285 (18.0) 90 (5.7) 360 (22.7) 40 (4.4) 50 (10) 65 (18) 130 (54) 40 (4.4) 115 (46)
090TSE 100 (6.3) 355 (22.4) 145 (9.1) 450 (28.4) 40 (4.4) 50 (10) 65 (18) 130 (54) 40 (4.4) 115 (46)
100TSE 100 (6.3) 385 (24.3) 145 (9.1) 450 (28.4) 40 (4.4) 50 (10) 65 (18) 130 (54) 40 (4.4) 115 (46)
115TSE 100 (6.3) 385 (24.3) 145 (9.1) 450 (28.4) 40 (4.4) 50 (10) 65 (18) 130 (54) 40 (4.4) 115 (46)
130TSE 140 (8.8) 625 (39.4) 180 (11.4) 700 (44.2) 40 (4.4) 50 (10) 65 (18) 130 (54) 40 (4.4) 115 (46)
150TSE 150 (9.5) 625 (39.4) 225 (14.2) 700 (44.2) 40 (4.4) 50 (10) 65 (18) 130 (54) 40 (4.4) 115 (46)
170TSE 200 (12.6) 650 (41.0) 260 (16.4) 700 (44.2) 40 (4.4) 50 (10) 65 (18) 130 (54) 40 (4.4) 115 (46)
200TSE 200 (12.6) 650 (41.0) 260 (16.4) 700 (44.2) 40 (4.4) 50 (10) 65 (18) 130 (54) 40 (4.4) 115 (46)
DESIGN PARAMETERS - HIGH EFFICIENCY (HE)
MODEL
EVAPORATOR
FLOW -
GPM (LPS)
CONDENSER
FLOW -
GPM (LPS)
LEAVING EVAP.
WATER TEMP. -
°F (°C)
ENT.
COND.
WATER
TEMP. -
°F (°C)
LVG.
COND.
WATER
TEMP. -
°F (°C)
EQUIPMENT
ROOM TEMP. -
°F (°C)
MIN MAX MIN MAX MIN
1
MAX
2
MIN MAX MIN MAX
060THE 100 (6.3) 355 (22.4) 145 (9.1) 450 (28.4) 40 (4.4) 50 (10) 65 (18) 130 (54) 40 (4.4) 115 (46)
070THE 140 (8.8) 625 (39.4) 145 (9.1) 450 (28.4) 40 (4.4) 50 (10) 65 (18) 130 (54) 40 (4.4) 115 (46)
080THE 140 (8.8) 625 (39.4) 145 (9.1) 450 (28.4) 40 (4.4) 50 (10) 65 (18) 130 (54) 40 (4.4) 115 (46)
090THE 140 (8.8) 625 (39.4) 225 (14.2) 700 (44.2) 40 (4.4) 50 (10) 65 (18) 130 (54) 40 (4.4) 115 (46)
095THE 150 (9.5) 625 (39.4) 225 (14.2) 700 (44.2) 40 (4.4) 50 (10) 65 (18) 130 (54) 40 (4.4) 115 (46)
115THE 140 (8.8) 625 (39.4) 225 (14.2) 700 (44.2) 40 (4.4) 50 (10) 65 (18) 130 (54) 40 (4.4) 115 (46)
130THE 200 (12.6) 650 (41.0) 225 (14.2) 700 (44.2) 40 (4.4) 50 (10) 65 (18) 130 (54) 40 (4.4) 115 (46)
150THE 200 (12.6) 650 (41.0) 260 (16.4) 700 (44.2) 40 (4.4) 50 (10) 65 (18) 130 (54) 40 (4.4) 115 (46)
NOTES:
1. For leaving brine temperature below 40˚ (4.4˚C), contact your local Quantech Sales Representative for application requirements.
2. For leaving water temperature above 50˚ (10˚C), contact your local Quantech Sales Representative for application requirements.
SECTION 5 – TECHNICAL DATA
