Quantech QWC3050T-200T User Manual

FORM QWC3-NM1
ISSUE DATE: 11/20/2020
SECTION 5 – TECHNICAL DATA
QUANTECH
48
SINGLE POINT ELECTRICAL DATA
Standard Efficiency Without External Compressor Overloads
MODEL
QWC3
VOLT HZ
MINIMUM
CIRCUIT
AMPS (MCA)
MIN N/F
DISC SW
MIN DUAL
ELEM FUSE
& MIN CB
MAX DUAL
ELEM FUSE
& MAX CB
LUGS PER PHASE
MODEL
QWC3
SYSTEM # 1 SYSTEM # 2
TERMINAL BLOCK
LUG SIZE (STD)
COMPR 1 COMPR 2 COMPR 3 COMPR 1 COMPR 2 COMPR 3
QTY/ ∅ LUG INFO RLA LRA RLA LRA RLA LRA RLA LRA RLA LRA RLA LRA
050TSE
208 60 206 400 250 250 1 # 10 - 300 KCM
050TSE
48.5 249 48.5 249 48.5 249 48.5 249
230 60 206 400 250 250 1 # 10 - 300 KCM 48.5 295 48.5 295 48.5 295 48.5 295
380 60 117 150 125 125 1 #10 - 3/0AWG 27.6 159 27.6 159 27.6 159 27.6 159
460 60 104 150 125 125 1 # 12 - 1 AWG 24.4 145 24.4 145 24.4 145 24.4 145
575 60 74 100 90 90 1 # 12 - 1 AWG 17.4 109 17.4 109 17.4 109 17.4 109
060TSE
200 60 237 400 300 300 1 # 4 - 500 KCM
060TSE
55.8 425 55.8 425 55.8 425 55.8 425
230 60 237 400 300 300 1 # 4 - 500 KCM 55.8 425 55.8 425 55.8 425 55.8 425
380 60 153 200 175 175 1 # 10 - 300 KCM 36.0 239 36.0 239 36.0 239 36.0 239
460 60 114 150 125 125 1 # 10 - 300 KCM 26.9 187 26.9 187 26.9 187 26.9 187
575 60 101 150 110 110 1 # 10 - 300 KCM 23.7 148 23.7 148 23.7 148 23.7 148
070TSE
200 60 278 400 300 350 1 # 4 - 500 KCM
070TSE
73.9 505 73.9 505 55.8 425 55.8 425
230 60 278 400 300 350 1 # 4 - 500 KCM 73.9 505 73.9 505 55.8 425 55.8 425
380 60 158 200 175 175 1 # 10 - 300 KCM 38.2 290 38.2 290 36.0 239 36.0 239
460 60 122 150 150 150 1 # 10 - 300 KCM 30.4 225 30.4 225 26.9 187 26.9 187
575 60 103 150 110 125 1 # 10 - 300 KCM 24.6 180 24.6 180 23.7 148 23.7 148
080TSE
200 60 314 400 350 350 1 # 4 - 500 KCM
080TSE
73.9 505 73.9 505 73.9 505 73.9 505
230 60 314 400 350 350 1 # 4 - 500 KCM 73.9 505 73.9 505 73.9 505 73.9 505
380 60 162 200 175 200 1 # 10 - 300 KCM 38.2 290 38.2 290 38.2 290 38.2 290
460 60 129 150 150 150 1 # 10 - 300 KCM 30.4 225 30.4 225 30.4 225 30.4 225
575 60 105 150 125 125 1 # 10 - 300 KCM 24.6 180 24.6 180 24.6 180 24.6 180
090TSE
200 60 348 400 400 400 2 # 10 - 300 KCM
090TSE
89.1 500 89.1 500 73.9 505 73.9 505
230 60 348 400 400 400 2 # 10 - 300 KCM 89.1 500 89.1 500 73.9 505 73.9 505
380 60 199 250 225 250 1 # 10 - 300 KCM 54.5 305 54.5 305 38.2 290 38.2 290
460 60 157 200 175 200 1 # 10 - 300 KCM 42.9 250 42.9 250 30.4 225 30.4 225
575 60 121 150 150 150 1 # 10 - 300 KCM 32.1 198 32.1 198 24.6 180 24.6 180
100TSE
200 60 379 600 450 450 2 # 10 - 300 KCM
100TSE
89.1 500 89.1 500 89.1 500 89.1 500
230 60 379 600 450 450 2 # 10 - 300 KCM 89.1 500 89.1 500 89.1 500 89.1 500
380 60 232 400 250 250 1 # 4 - 500 KCM 54.5 305 54.5 305 54.5 305 54.5 305
460 60 182 200 200 225 1 # 4 - 500 KCM 42.9 250 42.9 250 42.9 250 42.9 250
575 60 136 150 150 150 1 # 4 - 500 KCM 32.1 198 32.1 198 32.1 198 32.1 198
115TSE
208 60 380 600 450 450 2 # 10 - 300 KCM
115TSE
98.4 553 98.4 553 79.4 506 79.4 506
230 60 380 600 450 450 2 # 10 - 300 KCM 98.4 553 98.4 553 79.4 506 79.4 506
380 60 230 400 250 250 1 # 4 - 500 KCM 59.5 339 59.5 339 48.1 280 48.1 280
460 60 190 250 225 225 1 # 4 - 500 KCM 49.2 316 49.2 316 39.7 212 39.7 212
575 60 152 200 175 175 1 # 4 - 500 KCM 39.3 258 39.3 258 31.8 168 31.8 168
130TSE
208 60 418 600 500 500 2 # 4 - 500 KCM
130TSE
98.4 553 98.4 553 98.4 553 98.4 553
230 60 418 600 500 500 2 # 4 - 500 KCM 98.4 553 98.4 553 98.4 553 98.4 553
380 60 253 400 300 300 1 # 4 - 500 KCM 59.5 339 59.5 339 59.5 339 59.5 339
460 60 209 400 250 250 1 # 4 - 500 KCM 49.2 316 49.2 316 49.2 316 49.2 316
575 60 167 250 200 200 1 # 4 - 500 KCM 39.3 258 39.3 258 39.3 258 39.3 258
150TSE
208 60 453 600 500 500 2 # 4 - 500 KCM
150TSE
106.7 652 106.7 652 106.7 652 106.7 652
230 60 453 600 500 500 2 # 4 - 500 KCM 106.7 652 106.7 652 106.7 652 106.7 652
380 60 275 400 300 300 2 # 4 - 500 KCM 64.6 355 64.6 355 64.6 355 64.6 355
460 60 227 400 250 250 1 # 4 - 500 KCM 53.4 316 53.4 316 53.4 316 53.4 316
575 60 181 250 200 200 1 # 4 - 500 KCM 42.7 258 42.7 258 42.7 258 42.7 258
170TSE
460 60 258 400 300 300 1 # 4 - 500 KCM
170TSE
49.2 316 49.2 316 49.2 316 49.2 316 49.2 316
575 60 206 250 225 225 1 # 4 - 500 KCM 39.3 258 39.3 258 39.3 258 39.3 258 39.3 258
200TSE
460 60 308 400 350 350 1 # 4 - 500 KCM
200TSE
49.2 316 49.2 316 49.2 316 49.2 316 49.2 316 49.2 316
575 60 246 400 250 250 1 # 4 - 500 KCM 39.3 258 39.3 258 39.3 258 39.3 258 39.3 258 39.3 258
