Quantech QWC3050T-200T User Manual

FORM QWC3-NM1
ISSUE DATE: 11/20/2020
SECTION 2 – PRODUCT DESCRIPTION
QUANTECH
22
TABLE 1 - PRODUCT IDENTIFICATION NUMBER
FEATURE FEATURE DESCRIPTION OPTION OPTION DESCRIPTION
CONTRACT Contract Number NUM Contract Number = {CONTRACT/NUM}
ORDER Order quantity QTY Order quantity = {ORDER/QTY}
MODEL Model (PIN 1-4) QWC3 QWC3
CAP Capacity (PIN 5-8)
050T 050
060T 060
070T 070
080T 080
090T 090
095T 095
100T 100
115T 115
130T 130
150T 150
170T 170
200T 200
UNIT Unit Designator (PIN 9)
H High E󰀩ciency Unit
S Standard E󰀩ciency Unit
REF Refrigerant (PIN 10) E R-410A
VOLTS Voltage (PIN 11 and 12)
17 200/3/60
28 230/3/60
40 380/3/60
46 460/3/60
50 380-415/3/50
58 575/3/60
STARTER Starter (PIN 13)
X Across the Line Start
T Soft Start
DESIGN Design Series (PIN 14) A Design Series A
DEV Development Level (PIN 15) C Development Level A, B, or C
PRODUCT IDENTIFICATION NUMBER (PIN)
QWC3 050T S E 46 X
QWC3 = QUANTECH CHILLER WATER COOLED SCROLL
DESIGN
SERIES
VOLTAGE CODE:
17 = 200-3-60
28 = 230-3-60
40 = 380-3-60
46 = 460-3-60
58 = 575-3-60
C
DEVELOPMENT
LEVEL
A
X = ACROSS
THE LINE
REFRIGERANT = R-410a
MODEL
050T
060T
070T
080T
090T
095T
100T
115T
130T
150T
170T
200T
UNIT DESIGNATOR
H = High Efficiency
S = Standard Efficiency
