Quantech QWC3050T-200T User Manual

SECTION 2 – PRODUCT DESCRIPTION
FORM QWC3-NM1
ISSUE DATE:11/20/2020
QUANTECH
23
2
FEATURE FEATURE DESCRIPTION OPTION OPTION DESCRIPTION
POWER
Power Field (PIN 16 and 17)
XX Standard Power Option (SP Supply Terminal Block)
BX SP Circuit Breaker w/ Lockable Handle
SD SP Supply NF Disconnect Switch
MB MP Supply w/Ind Sys CB and L Ext Handles
QQ Special Quote
TRANS Control Transformer (PIN 18)
X No option
T Control Transformer (factory)
Q Special Quote
PFC Power Pin Capacitor (PIN 19)
X No option
C Power Factor Capacitor
Q Special Quote
PIN20 PIN 20
X No option
Q Special Quote
BAS BAS Interface (PIN 21)
X BAS/EMS Temp Reset/O󰀨set (Standard)
Q Special Quote
L LON E-Link Kit (Factory)
LCD Language (PIN 22)
X Standard (English) LCD and Keypad Display
F French LCD and Keypad Display
G German LCD and Keypad Display
I Italian LCD and Keypad Display
S Spanish LCD and Keypad Display
Q Special Quote
RDOUT Readout Kits (PIN 23)
X
Both Discharge and Suction Pressure Transducers /
Readout (Standard)
Q Special Quote
SAFETY Safety Codes (PIN 24)
C European Safety Code (CE)
L N American Safety Code (cUL/cETL)
Q Special Quote
HPUMP Heat pump (PIN 25)
X No option
H Heat Pump
Q Special Quote
CTEMP
Condenser Water Temp
(PIN 26 and 27)
XX No option
NUM
Leaving Condenser Water Temp = {CTEMP/NUM}
degrees
Q Special Quote
PIN 28 PIN 28
X No Sequence Kit
Q Special Quote
TEMP
Evaporator Water Temp
(PIN 29 and 30)
NUM
Leaving Evaporator Water Temp = {TEMP/NUM}
degrees
Q Special LST requirements
