Quantech QWC3050T-200T User Manual

FORM QWC3-NM1
ISSUE DATE: 11/20/2020
SECTION 5 – TECHNICAL DATA
QUANTECH
56
With External Compressor Overloads
DUAL POINT ELECTRICAL DATA
MODEL VOLT HZ
SYSTEM 1 WIRING SYSTEM 2 WIRING
MINIMUM
CIRCUIT
AMPS
MIN N/F
DISC SW
MIN DUAL
ELEM
FUSE
& MIN CB
MAX DUAL
ELEM
FUSE
& MAX CB
MINIMUM
CIRCUIT
AMPS
MIN N/F
DISC SW
MIN DUAL
ELEM
FUSE
& MIN CB
MAX DUAL
ELEM
FUSE
& MAX CB
050TSE
208 60 77 100 90 110 77 100 90 110
230 60 77 100 90 110 77 100 90 110
380 60 44 60 50 60 44 60 50 60
460 60 37 60 45 50 37 60 45 50
575 60 32 60 40 45 32 60 40 45
060TSE
060THE
208 60 95 100 110 125 95 100 110 125
230 60 95 100 110 125 95 100 110 125
380 60 58 60 70 80 58 60 70 80
460 60 48 60 60 60 48 60 60 60
575 60 39 60 45 50 39 60 45 50
070TSE
070THE
208 60 111 150 125 150 95 100 110 125
230 60 111 150 125 150 95 100 110 125
380 60 64 100 80 90 58 60 70 80
460 60 53 60 60 70 48 60 60 60
575 60 42 60 50 60 39 60 45 50
080TSE
080THE
208 60 111 150 125 150 111 150 125 150
230 60 111 150 125 150 111 150 125 150
380 60 64 100 80 90 64 100 80 90
460 60 53 60 60 70 53 60 60 70
575 60 42 60 50 60 42 60 50 60
090TSE
090THE
208 60 130 150 150 175 111 150 125 150
230 60 130 150 150 175 111 150 125 150
380 60 75 100 90 100 64 100 80 90
460 60 62 100 70 80 53 60 60 70
575 60 50 60 60 70 42 60 50 60
100TSE
208 60 130 150 150 175 130 150 150 175
230 60 130 150 150 175 130 150 150 175
380 60 75 100 90 100 75 100 90 100
460 60 62 100 70 80 62 100 70 80
575 60 50 60 60 70 50 60 60 70
115TSE
115THE
208 60 178 200 200 250 135 150 150 175
230 60 178 200 200 250 130 150 150 175
380 60 102 150 125 125 75 100 90 100
460 60 85 100 100 110 62 100 70 80
575 60 68 100 80 90 50 60 60 70
130TSE
208 60 178 200 200 250 178 200 200 250
230 60 178 200 200 250 178 200 200 250
380 60 102 150 125 125 102 150 125 125
460 60 85 100 100 110 85 100 100 110
575 60 68 100 80 90 68 100 80 90
