Quantech QWC3050T-200T User Manual

SECTION 5 – TECHNICAL DATA
FORM QWC3-NM1
ISSUE DATE:11/20/2020
QUANTECH
57
5
DUAL POINT ELECTRICAL DATA (CONT’D)
VOLT HZ
SYSTEM # 1 SYSTEM # 2
QTY./
Ø
CIRCUIT
BREAKER
LUG
SIZES
COMPR 1 COMPR 2 COMPR 3
QTY./
Ø
CIRCUIT
BREAKER
LUG
SIZES
COMPR 1 COMPR 2 COMPR 3
RLA LRA RLA LRA RLA LRA RLA LRA RLA LRA RLA LRA
208 60 (1) #14 - 1/0AWG 34.2 300 34.2 300 (1) #14 - 1/0AWG 34.2 300 34.2 300
230 60 (1) #14 - 1/0AWG 34.2 300 34.2 300 (1) #14 - 1/0AWG 34.2 300 34.2 300
380 60 (1) #14 - 1/0AWG 19.7 139 19.7 139 (1) #14 - 1/0AWG 19.7 139 19.7 139
460 60 (1) #14 - 1/0AWG 16.3 150 16.3 150 (1) #14 - 1/0AWG 16.3 150 16.3 150
575 60 (1) #14 - 1/0AWG 14.4 109 14.4 109 (1) #14 - 1/0AWG 14.4 109 14.4 109
208 60 (1) #2 - 4/0AWG 42.2 425 42.2 425 (1) #2 - 4/0AWG 42.2 425 42.2 425
230 60 (1) #2 - 4/0AWG 42.2 425 42.2 425 (1) #2 - 4/0AWG 42.2 425 42.2 425
380 60 (1) #14 - 1/0AWG 25.7 239 25.7 239 (1) #14 - 1/0AWG 25.7 239 25.7 239
460 60 (1) #14 - 1/0AWG 21.3 187 21.3 187 (1) #14 - 1/0AWG 21.3 187 21.3 187
575 60 (1) #14 - 1/0AWG 17.4 148 17.4 148 (1) #14 - 1/0AWG 17.4 148 17.4 148
208 60 (1) #2 - 4/0AWG 49.1 505 49.1 505 (1) #2 - 4/0AWG 42.2 425 42.2 425
230 60 (1) #2 - 4/0AWG 49.1 505 49.1 505 (1) #2 - 4/0AWG 42.2 425 42.2 425
380 60 (1) #14 - 1/0AWG 28.3 290 28.3 290 (1) #14 - 1/0AWG 25.7 239 25.7 239
460 60 (1) #14 - 1/0AWG 23.4 225 23.4 225 (1) #14 - 1/0AWG 21.3 187 21.3 187
575 60 (1) #14 - 1/0AWG 18.7 180 18.7 180 (1) #14 - 1/0AWG 17.4 148 17.4 148
208 60 (1) #2 - 4/0AWG 49.1 505 49.1 505 (1) #2 - 4/0AWG 49.1 505 49.1 505
230 60 (1) #2 - 4/0AWG 49.1 505 49.1 505 (1) #2 - 4/0AWG 49.1 505 49.1 505
380 60 (1) #14 - 1/0AWG 28.3 290 28.3 290 (1) #14 - 1/0AWG 28.3 290 28.3 290
460 60 (1) #14 - 1/0AWG 23.4 225 23.4 225 (1) #14 - 1/0AWG 23.4 225 23.4 225
575 60 (1) #14 - 1/0AWG 18.7 180 18.7 180 (1) #14 - 1/0AWG 18.7 180 18.7 180
208 60 (1) #6 - 350KCMIL 57.8 500 57.8 500 (1) #2 - 4/0AWG 49.1 505 49.1 505
230 60 (1) #6 - 350KCMIL 57.8 500 57.8 500 (1) #2 - 4/0AWG 49.1 505 49.1 505
380 60 (1) #14 - 1/0AWG 33.3 305 33.3 305 (1) #14 - 1/0AWG 28.3 290 28.3 290
460 60 (1) #14 - 1/0AWG 27.5 250 27.5 250 (1) #14 - 1/0AWG 23.4 225 23.4 225
575 60 (1) #14 - 1/0AWG 22.0 198 22.0 198 (1) #14 - 1/0AWG 18.7 180 18.7 180
208 60 (1) #6 - 350KCMIL 57.8 500 57.8 500 (1) #6 - 350KCMIL 57.8 500 57.8 500
230 60 (1) #6 - 350KCMIL 57.8 500 57.8 500 (1) #6 - 350KCMIL 57.8 500 57.8 500
380 60 (1) #14 - 1/0AWG 33.3 305 33.3 305 (1) #14 - 1/0AWG 33.3 305 33.3 305
460 60 (1) #14 - 1/0AWG 27.5 250 27.5 250 (1) #14 - 1/0AWG 27.5 250 27.5 250
575 60 (1) #14 - 1/0AWG 22.0 198 22.0 198 (1) #14 - 1/0AWG 22.0 198 22.0 198
208 60 (1) #6 - 350KCMIL 79.0 599 79.0 599 – – (1) #6 - 350KCMIL 59.8 500 59.8 500
230 60 (1) #6 - 350KCMIL 79.0 599 79.0 599 – – (1) #6 - 350KCMIL 57.8 500 57.8 500
380 60 (1) #2 - 4/0AWG 45.5 358 45.5 358 – – (1) #14 - 1/0AWG 33.3 305 33.3 305
460 60 (1) #14 - 1/0AWG 37.6 310 37.6 310 – – (1) #14 - 1/0AWG 27.5 250 27.5 250
575 60 (1) #14 - 1/0AWG 30.1 239 30.1 239 – – (1) #14 - 1/0AWG 22.0 198 22.0 198
208 60 (1) #6 - 350KCMIL 79.0 599 79.0 599 – – (1) #6 - 350KCMIL 79.0 599 79.0 599
230 60 (1) #6 - 350KCMIL 79.0 599 79.0 599 – – (1) #6 - 350KCMIL 79.0 599 79.0 599
380 60 (1) #2 - 4/0AWG 45.5 358 45.5 358 – – (1) #2 - 4/0AWG 45.5 358 45.5 358
460 60 (1) #14 - 1/0AWG 37.6 310 37.6 310 – – (1) #14 - 1/0AWG 37.6 310 37.6 310
575 60 (1) #14 - 1/0AWG 30.1 239 30.1 239 – – (1) #14 - 1/0AWG 30.1 239 30.1 239
