TABLE 30 - YORKTALK 2 COMMUNICATIONS DATA MAP (CONT’D)
Address Scale Imperial SI
Point List Description 12345678910
P70 AV34 YT2_ S01_ P70 nvoYTS01p070 SNVT_count_f (51)
ADF 34 0044 x10
PSI BAR Low Suction Pressure Cutout Cooling SSSS
P71 AV35 YT2_ S01_ P71 nvoYTS01p071 SNVT_count_f (51)
ADF 35 0045 x10
PSI BAR High Discharge Pressure Cutout SSSS
P72 AV36 YT2_ S01_ P72 nvoYTS01p072 SNVT_count_f (51)
ADF 36 0046 x10
°F °C Remote Setpoint SSSS
P73 AV37 YT2_ S01_ P73 nvoYTS01p073 SNVT_count_f (51)
ADF 37 0047 x10
°F °C Cooling Range SSSS
YT2_ S01_ P74
nvoYTS01p074 SNVT_count_f (51)
ADF 38 0048 x10
PSI
°F
BAR
°C
Remote Setpoint 2 (SP)
Remote Heating Setpoint (HP and YCWL HP)
OOOO
YT2_ S01_ P75
nvoYTS01p075 SNVT_count_f (51)
ADF 39 0049 x10
PSI
°F
BAR
°C
Cooling Range 2 (SP)
Heating Range (HP and YCWL HP)
OOOO
P76 AV40 YT2_ S01_ P76 nvoYTS01p076 SNVT_count_f (51)
ADF 40 0050 x10
°F °C Sys 1 Discharge Temperature (EEV) OOOO
P77 AV41 YT2_ S01_ P77 nvoYTS01p077 SNVT_count_f (51)
ADF 41 0051 x10
°F (diff) °C (diff) Sys 1 Discharge Superheat (EEV) OOOO
P78 AV42 YT2_ S01_ P78 nvoYTS01p078 SNVT_count_f (51)
ADF 42 0052 x10
°F °C Sys 2 Discharge Temperature (EEV) OOOO
P79 AV43 YT2_ S01_ P79 nvoYTS01p079 SNVT_count_f (51)
ADF 43 0053 x10
°F (diff) °C (diff) Sys 2 Discharge Superheat (EEV) OOOO
P80 BV25 YT2_ S01_ P80 nvoYTS01p080 SNVT_switch (95)
BD 25 0085
NNNN
P81 BV26 YT2_ S01_ P81 nvoYTS01p081 SNVT_switch (95)
BD 26 0086
NNNN
P82 BV27 YT2_ S01_ P82 nvoYTS01p082 SNVT_switch (95)
BD 27 0087
NNNN
P83 BV28 YT2_ S01_ P83 nvoYTS01p083 SNVT_switch (95)
BD 28 0088
NNNN
YT2_ S01_ P84
nvoYTS01p084 SNVT_switch (95)
0/1 0/1 SCC Auto Detect Available NSSS
Point List Code: S = Standard O = Optional N = Not Available
Ref
Object
Typ/Ins
BACnet Object
Name
LON Profile
Name
LON SNVT Type
N2
Metasys
Units
Modbus
Johnson Controls, Inc.
Subject to change without notice.
3 of 6
04/17/2018
