FORM QWC3-NM1
ISSUE DATE:11/20/2020
QUANTECH
3
MANUAL DESCRIPTION FORM NUMBER
Unit Replacement Parts QWC3--RP1
Unit Start-Up Checklist QWC3-CL1
All Products - Replacement Parts Electrical Connectors 50.20-RP1
All Products - Replacement Parts Fittings 50.20-RP2
ASSOCIATED LITERATURE
This manual contains installation, op-
eration and maintenance instructions for
both single and dual refrigerant circuit
models. If your unit is a single circuit
model (QTC2015T-030T), disregard refer-
ences to “System 2” which may appear in
this manual. Any references to Sys 2 are
applicable to QTC2015T-045T models.
SINGLE CIRCUIT AND DUAL CIRCUIT MODELS
CHANGEABILITY OF THIS DOCUMENT
In complying with Johnson Controls’ policy for con-
tinuous product improvement, the information con-
tained in this document is subject to change without
notice. Johnson Controls makes no commitment to
update or provide current information automatically
to the manual or product owner. Updated manuals, if
applicable, can be obtained by contacting the nearest
Johnson Controls Service office or accessing the John-
son Controls Knowledge Exchange website at https://
docs.johnsoncontrols.com/chillers/.
It is the responsibility of rigging, lifting, and operating/
service personnel to verify the applicability of these
documents to the equipment. If there is any question
regarding the applicability of these documents, rig-
ging, lifting, and operating/service personnel should
verify whether the equipment has been modified and
if current literature is available from the owner of the
equipment prior to performing any work on the chiller.
REVISION NOTES
Revisions made to this document are indicated in the following table. These revisions are to technical information,
and any other changes in spelling, grammar, or formatting are not included.
AFFECTED PAGES DESCRIPTION
46,47 Physical Data table units updated
48-55 Electrical Data table units updated
171-181 Data maps updated
