Quantech QWC3050T-200T User Manual

FORM QWC3-NM1
ISSUE DATE: 11/20/2020
SECTION 5 – TECHNICAL DATA
QUANTECH
52
Standard Efficiency With Optional External Compressor Overloads
SINGLE POINT ELECTRICAL DATA (CONT’D)
MODEL
QWC3
VOLT HZ
MINIMUM
CIRCUIT
AMPS
(MCA) *
MIN N/F
DISC SW
MIN
DUAL
ELEM
FUSE &
MIN CB
MAX
DUAL
ELEM
FUSE &
MAX CB
LUGS PER PHASE
MODEL
QWC3
SYSTEM # 1 SYSTEM # 2
DISCONNECT SWITCH
LUG SIZE (OPT)
CIRCUIT BREAKER
LUG SIZE (OPT)
COMPR 1 COMPR 2 COMPR 3 COMPR 1 COMPR 2 COMPR 3
QTY/ ∅
LUG INFO
QTY/ ∅
LUG INFO RLA LRA RLA LRA RLA LRA RLA LRA RLA LRA RLA LRA
050TSE
208 60 139 200 150 150 1 # 6 - 350 KCM 1 # 4 - 300 KCM
050TSE
32.7 249 32.7 249 32.7 249 32.7 249
230 60 121 150 125 125 1 # 6 - 350 KCM 1 # 4 - 300 KCM 28.4 295 28.4 295 28.4 295 28.4 295
380 60 73 100 90 90 1 # 14 - 1/0 AWG 1 # 14 - 1/0 AWG 17.2 159 17.2 159 17.2 159 17.2 159
460 60 60 100 70 70 1 # 14 - 1/0 AWG 1 # 14 - 1/0 AWG 14.2 145 14.2 145 14.2 145 14.2 145
575 60 48 60 50 50 1 # 14 - 1/0 AWG 1 # 14 - 1/0 AWG 11.4 109 11.4 109 11.4 109 11.4 109
060TSE
200 60 179 200 200 200 1 # 6 - 350 KCM 1 # 4 - 300 KCM
060TSE
42.2 425 42.2 425 42.2 425 42.2 425
230 60 179 200 200 200 1 # 6 - 350 KCM 1 # 4 - 300 KCM 42.2 425 42.2 425 42.2 425 42.2 425
380 60 109 150 125 125 1 # 2 - 4/0 AWG 1 # 2 - 4/0 AWG 25.7 239 25.7 239 25.7 239 25.7 239
460 60 91 100 100 110 1 # 14 - 1/0 AWG 1 # 14 - 1/0 AWG 21.3 187 21.3 187 21.3 187 21.3 187
575 60 74 100 80 90 1 # 14 - 1/0 AWG 1 # 14 - 1/0 AWG 17.4 148 17.4 148 17.4 148 17.4 148
070TSE
200 60 195 250 225 225 1 # 6 - 350 KCM 1 # 4 - 300 KCM
070TSE
49.1 505 49.1 505 42.2 425 42.2 425
230 60 195 250 225 225 1 # 6 - 350 KCM 1 # 4 - 300 KCM 49.1 505 49.1 505 42.2 425 42.2 425
380 60 115 150 125 125 1 # 2 - 4/0 AWG 1 # 2 - 4/0 AWG 28.3 290 28.3 290 25.7 239 25.7 239
460 60 95 150 110 110 1 # 2 - 4/0 AWG 1 # 2 - 4/0 AWG 23.4 225 23.4 225 21.3 187 21.3 187
575 60 77 100 90 90 1 # 14 - 1/0 AWG 1 # 14 - 1/0 AWG 18.7 180 18.7 180 17.4 148 17.4 148
080TSE
200 60 209 250 225 250 1 # 6 - 350 KCM 1 # 6 - 350 KCM
080TSE
49.1 505 49.1 505 49.1 505 49.1 505
230 60 209 250 225 250 1 # 6 - 350 KCM 1 # 6 - 350 KCM 49.1 505 49.1 505 49.1 505 49.1 505
380 60 120 150 150 150 1 # 2 - 4/0 AWG 1 # 2 - 4/0 AWG 28.3 290 28.3 290 28.3 290 28.3 290
460 60 99 150 110 110 1 # 2 - 4/0 AWG 1 # 14 - 1/0 AWG 23.4 225 23.4 225 23.4 225 23.4 225
575 60 80 100 90 90 1 # 14 - 1/0 AWG 1 # 14 - 1/0 AWG 18.7 180 18.7 180 18.7 180 18.7 180
090TSE
200 60 228 250 250 250 1 # 6 - 350 KCM 1 # 6 - 350 KCM
090TSE
57.8 500 57.8 500 49.1 505 49.1 505
230 60 228 250 250 250 1 # 6 - 350 KCM 1 # 6 - 350 KCM 57.8 500 57.8 500 49.1 505 49.1 505
380 60 132 150 150 150 1 # 2 - 4/0 AWG 1 # 2 - 4/0 AWG 33.3 305 33.3 305 28.3 290 28.3 290
460 60 109 150 125 125 1 # 2 - 4/0 AWG 1 # 2 - 4/0 AWG 27.5 250 27.5 250 23.4 225 23.4 225
575 60 87 100 100 100 1 # 14 - 1/0 AWG 1 # 14 - 1/0 AWG 22.0 198 22.0 198 18.7 180 18.7 180
100TSE
200 60 245 400 300 300 1 # 250 - 500 KCM 1 # 250 - 500 KCM
100TSE
57.8 500 57.8 500 57.8 500 57.8 500
230 60 245 400 300 300 1 # 250 - 500 KCM 1 # 250 - 500 KCM 57.8 500 57.8 500 57.8 500 57.8 500
380 60 141 200 150 150 1 # 6 - 350 KCM 1 # 4 - 300 KCM 33.3 305 33.3 305 33.3 305 33.3 305
460 60 117 150 125 125 1 # 2 - 4/0 AWG 1 # 2 - 4/0 AWG 27.5 250 27.5 250 27.5 250 27.5 250
575 60 94 150 100 110 1 # 14 - 1/0 AWG 1 # 14 - 1/0 AWG 22.0 198 22.0 198 22.0 198 22.0 198
115TSE
208 60 299 400 350 350 1 # 250 - 500 KCM 1 # 250 - 500 KCM
115TSE
78.4 553 78.4 553 61.2 506 61.2 506
230 60 260 400 300 300 1 # 250 - 500 KCM 1 # 250 - 500 KCM 68.2 553 68.2 553 53.2 506 53.3 506
380 60 157 200 175 175 1 # 6 - 350 KCM 1 # 4 - 300 KCM 41.3 339 41.3 339 32.2 280 32.2 280
460 60 130 200 150 150 1 # 6 - 350 KCM 1 # 4 - 300 KCM 34.1 316 34.1 316 26.6 212 26.6 212
575 60 104 150 125 125 1 # 2 - 4/0 AWG 1 # 2 - 4/0 AWG 27.3 258 27.3 258 21.3 168 21.3 168
130TSE
208 60 333 600 400 400 1 # 250 - 500 KCM 1 # 250 - 500 KCM
130TSE
78.4 553 78.4 553 78.4 553 78.4 553
230 60 290 400 350 350 1 # 250 - 500 KCM 1 # 250 - 500 KCM 68.2 553 68.2 553 68.2 553 68.2 553
380 60 176 250 200 200 1 # 6 - 350 KCM 1 # 4 - 300 KCM 41.3 339 41.3 339 41.3 339 41.3 339
460 60 145 200 175 175 1 # 6 - 350 KCM 1 # 4 - 300 KCM 34.1 316 34.1 316 34.1 316 34.1 316
575 60 116 150 125 125 1 # 2 - 4/0 AWG 1 # 2 - 4/0 AWG 27.3 258 27.3 258 27.3 258 27.3 258
150TSE
208 60 387 600 450 450 2 # 250 - 500 KCM 2 # 250 - 500 KCM
150TSE
91.1 652 91.1 652 91.1 652 91.1 652
230 60 337 600 400 400 1 # 250 - 500 KCM 1 # 250 - 500 KCM 79.2 652 79.2 652 79.2 652 79.2 652
380 60 204 400 225 250 1 # 6 - 350 KCM 1 # 6 - 350 KCM 47.9 355 47.9 355 47.9 355 47.9 355
460 60 168 250 200 200 1 # 6 - 350 KCM 1 # 6 - 350 KCM 39.6 316 39.6 316 39.6 316 39.6 316
575 60 135 200 150 150 1 # 4 - 300 KCM 1 # 2 - 4/0 AWG 31.7 258 31.7 258 31.7 258 31.7 258
170TSE
208 60 412 600 450 450 2 # 250 - 500 KCM 2 # 250 - 500 KCM
170TSE
78.4 553 78.4 553 78.4 553 78.4 553 78.4 553
230 60 358 400 400 400 2 # 250 - 500 KCM 2 # 250 - 500 KCM 68.2 553 68.2 553 68.2 553 68.2 553 68.2 553
380 60 217 400 250 250 1 # 250 - 500 KCM 1 # 6 - 350 KCM 41.3 339 41.3 339 41.3 339 41.3 339 41.3 339
460 60 179 250 200 200 1 # 6 - 350 KCM 1 # 4 - 300 KCM 34.1 316 34.1 316 34.1 316 34.1 316 34.1 316
575 60 143 200 150 150 1 # 6 - 350 KCM 1 # 2 - 4/0 AWG 27.3 258 27.3 258 27.3 258 27.3 258 27.3 258
200TSE
208 60 490 600 500 500 2 # 250 - 500 KCM 2 # 250 - 500 KCM
200TSE
78.4 553 78.4 553 78.4 553 78.4 553 78.4 553 78.4 553
230 60 426 600 450 450 2 # 250 - 500 KCM 2 # 250 - 500 KCM 68.2 553 68.2 553 68.2 553 68.2 553 68.2 553 68.2 553
380 60 258 400 300 300 1 # 250 - 500 KCM 1 # 250 - 500 KCM 41.3 339 41.3 339 41.3 339 41.3 339 41.3 339 41.3 339
460 60 213 250 225 225 1 # 6 - 350 KCM 1 # 4 - 300 KCM 34.1 316 34.1 316 34.1 316 34.1 316 34.1 316 34.1 316
575 60 171 200 175 175 1 # 6 - 350 KCM 1 # 4 - 300 KCM 27.3 258 27.3 258 27.3 258 27.3 258 27.3 258 27.3 258
