SECTION 5 – TECHNICAL DATA
FORM QWC3-NM1
ISSUE DATE:11/20/2020
QUANTECH
59
5
WITH EXTERNAL COMPRESSOR OVERLOADS
VOLT HZ
SYSTEM # 1 SYSTEM # 2
QTY./
Ø
CIRCUIT
BREAKER
LUG
SIZES
COMPR 1 COMPR 2 COMPR 3
QTY./
Ø
CIRCUIT
BREAKER
LUG
SIZES
COMPR 1 COMPR 2 COMPR 3
RLA LRA RLA LRA RLA LRA RLA LRA RLA LRA RLA LRA
208 60 (1) #6 - 350KCMIL 42.2 425 42.2 425 42.2 425 (1) #6 - 350KCMIL 42.2 425 42.2 425 42.2 425
230 60 (1) #6 - 350KCMIL 42.2 425 42.2 425 42.2 425 (1) #6 - 350KCMIL 42.2 425 42.2 425 42.2 425
380 60 (1) #14 - 1/0AWG 25.7 239 25.7 239 25.7 239 (1) #14 - 1/0AWG 25.7 239 25.7 239 25.7 239
460 60 (1) #14 - 1/0AWG 21.3 187 21.3 187 21.3 187 (1) #14 - 1/0AWG 21.3 187 21.3 187 21.3 187
575 60 (1) #14 - 1/0AWG 17.4 148 17.4 148 17.4 148 (1) #14 - 1/0AWG 17.4 148 17.4 148 17.4 148
208 60 (1) #6 - 350KCMIL 49.1 505 49.1 505 49.1 505 (1) #6 - 350KCMIL 49.1 505 49.1 505 49.1 505
230 60 (1) #6 - 350KCMIL 49.1 505 49.1 505 49.1 505 (1) #6 - 350KCMIL 49.1 505 49.1 505 49.1 505
380 60 (1) #14 - 1/0AWG 28.3 290 28.3 290 28.3 290 (1) #14 - 1/0AWG 28.3 290 28.3 290 28.3 290
460 60 (1) #14 - 1/0AWG 23.4 225 23.4 225 23.4 225 (1) #14 - 1/0AWG 23.4 225 23.4 225 23.4 225
575 60 (1) #14 - 1/0AWG 18.7 180 18.7 180 18.7 180 (1) #14 - 1/0AWG 18.7 180 18.7 180 18.7 180
208 60 (1)
#6 - 350KCMIL
51.1 505 51.1 505 51.1 505 (1)
#6 - 350KCMIL
79.0 599 79.0 599 – –
230 60 (1) #6 - 350KCMIL 49.1 505 49.1 505 49.1 505 (1) #6 - 350KCMIL 79.0 599 79.0 599 – –
380 60 (1) #14 - 1/0AWG 28.3 290 28.3 290 28.3 290 (1) #2 - 4/0AWG 45.5 358 45.5 358 – –
460 60 (1) #14 - 1/0AWG 23.4 225 23.4 225 23.4 225 (1) #14 - 1/0AWG 37.6 310 37.6 310 – –
575 60 (1)
#14 - 1/0AWG
18.7 180 18.7 180 18.7 180 (1)
#14 - 1/0AWG
30.1 239 30.1 239 – –
208 60 (1) #6 - 350KCMIL 57.8 500 57.8 500 57.8 500 (1) #6 - 350KCMIL 57.8 500 57.8 500 57.8 500
230 60 (1) #6 - 350KCMIL 57.8 500 57.8 500 57.8 500 (1) #6 - 350KCMIL 57.8 500 57.8 500 57.8 500
380 60 (1) #2 - 4/0AWG 33.3 305 33.3 305 33.3 305 (1) #2 - 4/0AWG 33.3 305 33.3 305 33.3 305
460 60 (1) #14 - 1/0AWG 27.5 250 27.5 250 27.5 250 (1) #14 - 1/0AWG 27.5 250 27.5 250 27.5 250
575 60 (1) #14 - 1/0AWG 22.0 198 22.0 198 22.0 198 (1) #14 - 1/0AWG 22.0 198 22.0 198 22.0 198
208 60 (1)
# 250 - 500 KCM
90.5 599 90.5 599 – – (1)
# 4 - 300 KCM
90.5 599 90.5 599 – –
230 60 (1) # 250 - 500 KCM 78.7 599 78.7 599 – – (1) # 4 - 300 KCM 78.7 599 78.7 599 – –
380 60 (1) #2 - 4/0AWG 47.7 358 47.7 358 – – (1) #2 - 4/0AWG 47.7 358 47.7 358 – –
460 60 (1) #2 - 4/0AWG 39.4 310 39.4 310 – – (1) #14 - 1/0AWG 39.4 310 39.4 310 – –
575 60 (1)
#14 - 1/0AWG
31.5 239 31.5 239 – – (1)
#14 - 1/0AWG
31.5 239 31.5 239 – –
DUAL POINT ELECTRICAL DATA (CONT’D)
