Communication Protocol CubiScan 25 Command Set
CubiScan 25 Service Manual 61
Gate Measure
The CubiScan 25 will automatically send measurement data upon completion of a gate
measurement. The dimensions of the object that was measured will be sent.
2 1 Flash Command Alpha (f) 66h
31End of Text Control(ETX) 03h
4 1 Carriage Return Control (CR) 0Dh
51Line Feed Control(LF) 0Ah
Acknowledge Format
1 1 Start of Text Control (STX) 02h
2 1 Flash Command Alpha (f) 66h
3 1 Acknowledge Alpha (A) 41h
41End of Text Control(ETX) 03h
5 1 Carriage Return Control (CR) 0Dh
61Line Feed Control(LF) 0Ah
Negative Acknowledge Format
1 1 Start of Text Control (STX) 02h
2 1 Flash Command Alpha (f) 66h
31Neg. Acknowledge Alpha (N) 4Eh
41End of Text Control(ETX) 03h
5 1 Carriage Return Control (CR) 0Dh
61Line Feed Control(LF) 0Ah
Pos Len Description Type Range ASCII
Acknowledge Format
1 1 Start of Text Control (STX) 02h
2 1 Measure Command Alpha (m) 6Dh
3 1 Acknowledge Alpha (A) 41h
41
CubiScan/Host
Originated
Alpha (C/H) 43h or 48h
Pos Len Description Type Range ASCII
