Communication Protocol CubiScan 25 Command Set
CubiScan 25 Service Manual 63
Identification/Serial Number
This command causes the CubiScan 25 to change its current serial number data field. The serial
number is an eight-digit code which uniquely identifies the CubiScan 25.
7 1 Carriage Return Control (CR) 0Dh
81Line Feed Control(LF) 0Ah
Pos Len Description Type Range ASCII
Command Format
1 1 Start of Text Control (STX) 02h
2 1 ID Serial # Command Alpha (I) 49h
3 8 Serial Number Numeric
00000000-
99999999
11 1 End of Text Control (ETX) 03h
12 1 Carriage Return Control (CR) 0Dh
13 1 Line Feed Control (LF) 0Ah
Acknowledge Format
1 1 Start of Text Control (STX) 02h
2 1 ID Serial # Command Alpha (I) 49h
3 1 Acknowledge Alpha (A) 41h
41End of Text Control(ETX) 03h
5 1 Carriage Return Control (CR) 0Dh
61Line Feed Control(LF) 0Ah
Negative Acknowledge Format
1 1 Start of Text Control (STX) 02h
2 1 ID Serial # Command Alpha (I) 49h
31Neg. Acknowledge Alpha (N) 4Eh
41End of Text Control(ETX) 03h
5 1 Carriage Return Control (CR) 0Dh
61Line Feed Control(LF) 0Ah
Pos Len Description Type Range ASCII
