Quantum FIREBALL PLUS AS 10.2 User Manual

ATA Bus Interface and ATA Commands
6-84 Quantum Fireball Plus AS 10.2/20.5/30.0/40.0/60.0 GB AT
SET MAX UNLOCK
SET MAX UNLOCKSET MAX UNLOCK
SET MAX UNLOCK
Command Code
Command CodeCommand Code
Command Code
F9h with the content of the Features register equal to 03h.
Inputs
InputsInputs
Inputs
Description
DescriptionDescription
Description
This command requests a transfer of a single sector of data from the host. The Table
below defines the content of this sector of information.
The password supplied in the sector of data transferred will be compared with the
stored SET MAX password.
If the password comparison fails, then the device returns command aborted and
decrements the unlock counter. On the acceptance of the SET MAX LOCK
command, this counter is set to a value of five and will be decremented for each
password mismatch when SET MAX UNLOCK is issued and the device is locked.
When this counter reaches zero, then the SET MAX UNLOCK command will
return command aborted until a power cycle.
If the password compare matches, then the device will make a transition to the
Set_Max_Unlocked state and all SET MAX commands will be accepted.
Register
RegisterRegister
Register 7
77
76
66
65
55
54
44
43
33
32
22
21
11
10
00
0
Features 03h
Sector Count na
Sector Number na
Cylinder Low na
Cylinder High na
Device/Head obs na obs DEV na
Command F9h
WORD
WORDWORD
WORD CONTENT
CONTENTCONTENT
CONTENT
0 Reserved
1 - 16 Password (32 bytes)
17 - 255 Reserved
