Specifications
4-8 Quantum Fireball Plus AS 10.2/20.5/30.0/40.0/60.0 GB AT
4.7
4.74.7
4.7 MECHANICAL
MECHANICALMECHANICAL
MECHANICAL
Quantum Fireball Plus AS hard disk drives are designed to meet the form factor
dimensions of the SFF committee specification SFF8300.
Height: 26.1 mm maximum
Width: 101.6 ± 0.25mm
Depth: 147 mm maximum
Weight: 1.35 lb
4.8
4.84.8
4.8 ENVIRONMENTAL CONDITIONS
ENVIRONMENTAL CONDITIONSENVIRONMENTAL CONDITIONS
ENVIRONMENTAL CONDITIONS
Table 4-7 summarizes the environmental specifications of the Quantum Fireball
Plus AS hard disk drives.
Table 4-7
Table 4-7 Table 4-7
Table 4-7 Environmental Specifications
1. Maximum operating temperature must not exceed the drive at any point along
the drive form factor envelope. Airflow or other means must be used as needed
to meet this requirement.
2. The humidity range shown is applicable for temperatures whose combination
does not result in condensation in violation of the wet bulb specifications.
3. Altitude is relative to sea level.
4. The specified drive uncorrectable error rate will not be exceeded over these
conditions.
PARAMETER
PARAMETERPARAMETER
PARAMETER OPERATING
OPERATINGOPERATING
OPERATING NON-OPERATING
NON-OPERATINGNON-OPERATING
NON-OPERATING
Temperature
1
(Non-condensing)
5° to 55°C
(41° to 131°F)
-40° to 65°C
(-40° to 149°F)
Temperature Gradient
(Non-condensing)
20°C/hr maximum
(68°F/hr)
30°C/hr maximum
(86°F/hr)
Humidity
2
(Non-condensing)
Maximum Wet Bulb
Temperature
10% to 85% RH
30°C (86°F)
5% to 95% RH
40°C (104°F)
Humidity Gradient 10% / hour 10% / hour
Altitude
3, 4
–200 m to 3,000 m
(–650 to 10,000 ft.)
–200 m to 12,000 m
(–650 to 40,000 ft.)
Altitude Gradient 1.5 kPa/min 8 kPa/min
