Installation
Quantum Fireball Plus AS 10.2/20.5/30.0/40.0/60.0 GB AT 3-13
3.7
3.73.7
3.7 FOR SYSTEMS WITH A MOTHERBOARD ATA ADAPTER
FOR SYSTEMS WITH A MOTHERBOARD ATA ADAPTERFOR SYSTEMS WITH A MOTHERBOARD ATA ADAPTER
FOR SYSTEMS WITH A MOTHERBOARD ATA ADAPTER
You can install the Quantum Fireball Plus AS 10.2/20.5/30.0/40.0/60.0 GB AT
hard disk drives in an AT-compatible system that contains a 40-pin ATA bus
connector on the motherboard.
To connect the drive to the motherboard, use a 40 conductor ribbon cable (80
conductor ribbon cable if using Ultra ATA/100 drive) 18 inches in length or
shorter. Ensure that pin 1 of the drive is connected to pin 1 of the motherboard
connector.
3.8
3.83.8
3.8 FOR SYSTEMS WITH AN ATA ADAPTER BOARD
FOR SYSTEMS WITH AN ATA ADAPTER BOARDFOR SYSTEMS WITH AN ATA ADAPTER BOARD
FOR SYSTEMS WITH AN ATA ADAPTER BOARD
To install the Quantum Fireball Plus AS 10.2/20.5/30.0/40.0/60.0 GB AT hard
disk drive in an AT-compatible system without a 40-pin ATA bus connector on its
motherboard, you need a third-party IDE-compatible adapter board.
3.8.1
3.8.13.8.1
3.8.1 Adapter Board Installation
Adapter Board InstallationAdapter Board Installation
Adapter Board Installation
Carefully read the manual that accompanies your adapter board before installing
it. Make sure that all the jumpers are set properly and that there are no address or
signal conflicts. You must also investigate to see if your AT-compatible system
contains a combination floppy and hard disk controller board. If it does, you must
disable the hard disk drive controller functions on that controller board before
proceeding.
Once you have disabled the hard disk drive controller functions on the floppy/
hard drive controller, install the adapter board. Again, make sure that you have
set all jumper straps on the adapter board to avoid addressing and signal conflicts.
Note: For Sections 3.7 and 3.8, power should be turned off on the
computer before installing the drive.
