Wi-Fi&Bluetooth Module Series
FC64E_Hardware_Design
15
/ 53
2 Product Overview
2.1. General Description
The module is a Wi-Fi and Bluetooth module with low power consumption. It is a single-die WLAN
(Wireless Local Area Network) and Bluetooth combo solution supporting IEEE 802.11a/b/g/n/ac/ax
2.4/5 GHz WLAN standards and Bluetooth 5.1 standard, which enables seamless integration of WLAN
and Bluetooth low energy technologies.
With a low-power PCIe Gen 3 interface for WLAN, a UART and PCM* interface for Bluetooth, FC64E can
provide WLAN and Bluetooth functions.
2.2. Key Features
The following table describes the key features of the module.
Table 2: Key Features
Core supply voltage: 0.95 V, 1.35 V, 1.95 V
I/O supply voltage: 1.8 V
RF supply voltage: 2.2 V, 3.3 V (optional)
2.4 GHz WLAN: 2.400–2.4835 GHz
5 GHz WLAN: 5.150–5.850 GHz
Bluetooth: 2.402–2.480 GHz
FC62E:
Compliant with IEEE 802.11a/b/g/n/ac/ax
Dual band 2.4/5 GHz chains: 20/40 MHz channel bandwidth for 2.4 GHz
and 20/40/80 MHz channel bandwidth for 5 GHz
Supports 2 × 2 Multi-User Multiple-Input Multiple-Output
(MU-MIMO)
up to 1200 Mbps data rate (2 × 2 11ax)
FC64E:
