For more details about RF layout, see document [3].
3.8.4. Requirements for Antenna Design
The following table shows the requirements for antennas.
Table 16: Antenna Requirements
3.8.5. RF Connector Recommendation
If RF connector is used for antenna connection, it is recommended to use U.FL-R-SMT connector
provided by Hirose.
Type
Requirements
Frequency Range
2.400–2.4835 GHz
5.180–5.825 GHz
VSWR
< 2:1 (Recommended)
Gain
1 dBi (Typ.)
Max. Input Power
50 W
Input Impedance
50 Ω
Polarization Type
Vertical
Cable insertion loss
< 1 dB
