Quectel FC64E - Operating and Storage Temperatures; Power Consumption; Power Consumption in Low Power Modes

Wi-Fi&Bluetooth Module Series
FC64E_Hardware_Design
40
/ 53
4.4. Operating and Storage Temperatures
Table 20: Operating and Storage Temperatures
4.5. Power Consumption
The following tables show the power consumption of the module in different modes.
4.5.1. Power Consumption in Low Power Modes
Table 21: Power Consumption of the Module (Low Power Modes, unit: mA)
4.5.2. Power Consumption
Table 22: TX Power Consumption (Unit: mA)
2
Within operating temperature range, the module is IEEE compliant.
3
In OFF state, the Wi-Fi driver is uninstalled and WLAN_EN is pulled down.
4
In Idle state, the Wi-Fi is enable but not connected.
Parameter
Min.
Typ.
Max.
Unit
Operating Temperature Range
2
-30
25
+85
ºC
Storage Temperature Range
-40
+95
ºC
Module
State
Wi-Fi State
VDD_CORE_
VL (0.95 V)
VDD_CORE_
VM (1.35 V)
VDD_CORE_
VH (1.95 V)
VDD_IO
(1.8 V)
VDD_RF
(2.2 V)
OFF
3
Wi-Fi disabled
0.12
0.08
0.07
2.1
0.2
Idle
4
Wi-Fi disconnect
257.84
104.27
46.99
2.2
30.33
Description
Conditions
VDD_CORE_
VL (0.95 V)
VDD_CORE_
VM (1.35 V)
VDD_CORE_
VH (1.95 V)
VDD_IO
(1.8 V)
VDD_RF
(2.2 V)
1 × 1
2G 802.11b
1Mbps
300.42
136.38
93.6
2.93
366.89
