Quectel FC64E User Manual

Wi-Fi&Bluetooth Module Series
FC64E_Hardware_Design
42
/ 53
4.6. RF Performances
The following tables summarize the transmitting and receiving performances of FC64E.
4.6.1. Conducted RF Output Power
Table 23: Conducted RF Output Power at 2.4 GHz
11n MCS7
HT40
526.4
316.91
218.83
2.91
1087
11n MCS0
HT20 + 11ac
MCS0
VHT20
424.04
306.3
223.24
2.91
1342
11n MCS7
HT40 + 11ac
MCS9
VHT80
672.59
319.42
218.2
2.9
1127
11ax MCS0
HE20
429.49
311.57
232.78
2.91
1355
11ax
MCS11 2G
HE40 + 5G
HE80
674.75
324.69
228.4
2.92
1111
Description
Min.
Typ.
Unit
802.11b @ 1 Mbps
15
17
dBm
802.11b @ 11 Mbps
15
17
dBm
802.11g @ 6 Mbps
14
16
dBm
802.11g @ 54 Mbps
12
14
dBm
802.11n, HT20 @ MCS0
14
16
dBm
802.11n, HT20 @ MCS7
12
14
dBm
802.11n, HT40 @ MCS0
14
16
dBm
802.11n, HT40 @ MCS7
12
14
dBm
