4.7. Bluetooth RF Performances
The following tables summarize the transmitting and receiving performances of FC64E.
4.7.1. Conducted RF Output Power
Table 27: Conducted RF Output Power
802.11ac, VHT20 @ MCS8
-66 dBm
802.11ac, VHT40 @ MCS0
-87 dBm
802.11ac, VHT40 @ MCS9
-62 dBm
802.11ac, VHT80 @ MCS0
-84 dBm
802.11ac, VHT80 @ MCS9
-58 dBm
802.11ax, HE20 @ MCS0
-90 dBm
802.11ax, HE20 @ MCS11
-60 dBm
802.11ax, HE40 @ MCS0
-87 dBm
802.11ax, HE40 @ MCS11
-57 dBm
802.11ax, HE80 @ MCS0
-84 dBm
802.11ax, HE80 @ MCS11
-55 dBm
Description
Min.
Typ.
Unit
GFSK
TBD
TBD
dBm
Π/4-DQPSK
TBD
TBD
dBm
8-DQPSK
TBD
TBD
dBm
BLE_1M
TBD
TBD
dBm
BLE_2M
TBD
TBD
dBm
