Quectel FC64E User Manual

Wi-Fi&Bluetooth Module Series
FC64E_Hardware_Design
38
/ 53
4 Electrical Characteristics & Reliability
4.1. General Description
This chapter mainly introduces electrical and radio characteristics of FC64E module. The details are listed
in the subsequent chapters.
4.2. Electrical Characteristics
The following table shows the absolute maximum ratings.
Table 17: Absolute Maximum Ratings
The following table shows the recommended operating conditions of the module.
Parameter
Min.
Max.
Unit
VDD_CORE_VL
-0.3
V
DDX
+ 0.2
V
VDD_CORE_VM
-0.3
V
DDX
+ 0.2
V
VDD_CORE_VH
-0.3
V
DDX
+ 0.2
V
VDD_IO
-0.3
V
DDX
+ 0.2
V
VDD_RF
-0.3
V
DDX
+ 0.2
V
Digital I/O input voltage
-0.3
VDD_IO + 0.2
V
V
DDX
is the external supply voltage for the corresponding power input pins.
NOTE
