Quidel Triage MeterPro - Page 14

Page14of86

On/OffKey
(Powerbutton)

UsedtoturntheQuidelTriageMeterProonandoff.
PrintKey

Usedtoprintthetestresultsordisplayscreen.
DeleteKey

Usedtodeletedata.
EnterKey

Allowstheoperatortoselectmenuitemsandacknowledgealarm
conditions.
ExitKey

Usedtoexitthedisplayedmenuorejectthetestdevice.
BrightnessKey

Usedtosetscreenbrightness
Keypad

Usedtoenteridentificationnumbers,letters,andspecialsymbols.
ArrowKeys





Usedtotogglethroughmenuitems.
Up
Down
Left
Right
ShiftKey


SymbolKey

UsedwithShiftKey
ThermalPrinter

Printsthetestresultonpaper.
DataPort

Connectionpointforthe(optional)BarCodeScanner,allowingthe
operatortoscanpatientoruseridentificationdatainsteadofmanually
enteringnumbersorlettersonthekeypad.Mayalsobeusedtoconnect
toadatamanagementsystem/LIS.
PaperFeedKey

Usedtofeedpaper
CODECHIP
ModulePort

InsertionpointforCODECHIPmoduleswhichcontainlot/devicespecific
dataforuseinprovidingtestresults.
PowerSupplyPort  ConnectionpointforthesuppliedAC/ DCPowerConverter.
PrinterCover  Thecover,whichwhenpulledstraightup,revealsthepaperroll.
LCDScreen 
TheLCD(LiquidCrystalDisplay)Screenshowsthemenuofpossibletests
andtasksandpromptstheoperatortotakethenextstep.
ScreencommandsandoptionsareindicatedbyaBOLDEDFONT. 
