3 Technical Specifications
Time to digital converters
Digital resolution
1 ps
Timing jitter – RMS, FWHM
20 ps, 50 ps
Max. event rate per channel
100 Mcps
Sustained throughput rate
100 Mcps (USB3.0)
Delay range
-50 … +50 ns
Delay resolution
1 ps
Min. pulse to pulse separation
10 ns
Differential non-linearity
<1%
Max. acquisition time without overflow
1.25 h
Input Channels
Number of channels
1 start / 8, 16, 32 stop
Connector
SMA
Signal level range
-5.0 V … + 3.5 V, e.g. LVTTL, NIM
Offset voltage max.
± 10 mV
Min. input level
± 50 mV
Threshold level resolution
0.15 mV
Threshold voltage range
- 3.0 V… + 3.0 V
Threshold voltage offset max.
± 25 mV
Edge
Rising, falling
Min. input pulse width
1 ns
Termination
50 Ohm
Output Channels
Number of channels
2
Connector
D-Sub, Pins 3 & 1
Signal levels
LVTTL
Delay range
-100… 100 ns
Delay resolution
10 ps
Impedance
50 Ohm
