28 quTAG MC Manual www.qutools.com
The available models for the lifetime function are shown below:
Exponential fit
Double exponential fit
Kohlrausch fit
The "Data Generation" dialog allows to demonstrate the functions with data generated by one
of the model functions.
7.6 Detector Parameter Settings
Input parameter settings like the trigger level and rising/falling edge detection can be configured
in the "Detector Parameters". After a restart of the device, all channels are by default configured
to detect the rising edge of input signals at a trigger level of 1 V, which is suitable for LVTTL
signals.
Figure 14: Input parameter settings in Daisy
