• Base
Only one Base station should be present within one radio coverage when Base driven
protocol is used.
Italicised parameters are described in Common parameters.
Mode
Modulation type
Modulation rate
FEC
Remotes
Radio protocol parameters for every Remote station must be configured in this table.
Group(s) of remotes can be configured together if assigned within an interval of Pro-
tocol addresses.
Protocol address
Protocol address [0 to 255] is the unique address assigned to each Remote and
is only used by Base driven protocol. It is set in Remote unit in its Radio protocol
settings. The default and recommended setting assigns Protocol address to be
equal to the Radio IP last byte (Protocol address mode in Remote unit is set to
Automatic then).
There are two possibilities to fill in the Protocol address in the table:
Write down one Protocol address (e.g. "10").
Write down an interval of Protocol addresses (e.g. "10-29"). The settings are applied
to all addresses within the interval.
Note
If you configure any Remote station Protocol addresses which are not
present in the running network, radio channel access will be granted
to them regularly resulting in lower total network throughput: Every
address listed in this table will be taken into consideration when config-
uring radio channel access. It is possible to prepare configuration for
an additional radio unit in the network if needed. The "Active" parameter
(see below) within such a table record can be marked as not active. In
this case, the record is never granted radio channel access.
Modulation rate
Set value is used in both directions from Base to Remote and from Remote to
Base. If the Remote station is behind Repeater, set value is used for both radio
hops: Base station - Repeater and Repeater - Remote.
FEC
Set value is used in both directions from Base to Remote and from Remote to
Base. If the Remote station is behind Repeater, set value is used for both radio
hops: Base station - Repeater and Repeater - Remote.
ACK
