Figure 1-4 Typical point-to-point application
OTU1
OTU2
iTN8600-A
OTU2
FE/GE/10GE/
STM-N
Access OTN
remote device
iTN8600-I
10GE/STM-64
40GE/100GE
8G/10G/16G FC
customer device
NView NNM
DCN
iTN8600-I
OTU4
iTN8600-A
OTU1
OTU2
FE/GE/10GE/
STM-N
10GE/STM-64
40GE/100GE
8G/10G/16G FC
customer device
Access OTN
remote device
OTU2
Dual fibers
Typical point-to-point WDM application
As shown in Figure 1-5, based on point-to-point application, the iTN8600-I is connected
downstream to the WDM network, so it supports higher bandwidth, 10/100 Gbit/s hybrid
transmission, and smooth upgrade.
