Raisecom iTN8600-I User Manual

Raisecom
iTN8600-I (A) Product Description
3 Cards and parts
Raisecom Proprietary and Confidential
Copyright © Raisecom Technology Co., Ltd.
20
3.2.6 Technical specifications
Table 3-9 Technical specifications of the RPD2153-48D483V3
Parameter
Description
Rated input voltage (V)
-48
Input voltage range (V)
-40 to -57
Input surge current (A)
40
Power input
-48 V, 4 A
3.2.7 Cable
Table 3-10 DC power cable
Model
Description
POL-DC-unstripped/stripped-
1.0mm2-4m/RoHS
DC power cable, used for the DC power supply, used
with the 5.08-3Pin-header/RoHS connector
3.3 AC power supply RPA1171-220S12
3.3.1 Version
Table 3-11 Version of the AC power supply
Model
Version
RPA1171-220S12
A.00 or later
3.3.2 Appearance
Figure 3-3 shows the panel of the AC power supply, including the captive screw, heat
dissipation holes, handle, power LED, power interface, and power cable clip.
