Mode
l
Tx
wavelen
gth (nm)
Rx
wavelength
(nm)
Tx optical
power
(dBm)
Overl
oad
(dBm)
Extinctio
n ratio
(dB)
Rx
sensitivity
(dBm)
Mo
de
Trans
missio
n
distan
ce
(km)
UQP-
100G/
ER4L

1295.56

1300.05

1304.58

1309.14

1294.53–
1296.59

1299.02–
1301.09

1303.54–
1305.63

1308.09–
1310.19

Single
channel: -
2.9 to 4.5

Total: <
10.5
> -3.0
> 7

BER=1E-
12: < -
14.5

BER=5E-
5: < -18.5
SM
30
5.1.6 UC2
103.1 Gbit/s and 111.8 Gbit/s (LC/PC, dual-fiber bidirectional, compatible with
100GE and OTU4)
Table 5-12 Parameters of the UC2 module (103.1 Gbit/s and 111.8 Gbit/s, LC/PC, dual-fiber
bidirectional, compatible with 100GE and OTU4)
Model
Tx
wavelen
gth (nm)
Rx
wavelength
(nm)
Tx optical
power per
channel
(dBm)
Overloa
d
(dBm)
Extinc
tion
ratio
(dB)
Rx
sensitivity
per
channel
(dBm)
Mo
de
Trans
missio
n
distan
ce
(km)
UC2-
100G/
LR4

1295.56

1300.05

1304.58

1309.14

1294.53–
1296.59

1299.02–
1301.09

1303.54–
1305.63

1308.09–
1310.19

100GE: -4.3
to 4.5

OTU4: -0.6 to
4.0
> 5.5
> 4

100GE: <
-8.6

OTU4: < -
8.4
SM
10
UC2-
100G/
ER4

1295.56

1300.05

1304.58

1309.14

1294.53–
1296.59

1299.02–
1301.09

1303.54–
1305.63

1308.09–
1310.19

100GE: -2.9
to 2.9

OTU4: -2.7 to
2.9
> 5.5
> 7

100GE: <
-21.4

OTU4: < -
23.2
SM
40
