iTN8600-I (A) Product Description
1 Overview
Raisecom Proprietary and Confidential
Copyright © Raisecom Technology Co., Ltd.
7
Model
Description
GCC or VLAN in-band network management.

Two types of power supplies support 1+1 protection. The iTN8600-I-
XT4D-DC is the dual -48 VDC power model. The iTN8600-I-XT4D-AC is
the dual 220 VDC power model.

The 10G Any services include 10GE/OTU2/OTU2e/STM-64/8G FC/10G FC
services.

Two power supplies support automatic 1+1 hot backup. They must be connected
to different power sourcing equipment or lines to prevent the iTN8600-I from being
powered off due to power failure of one power sourcing equipment or line.

There are 6 modes for client-side services. The maximum total bandwidth of
services on all client-side interfaces is 200 Gbit/s. Table 1-2 lists different modes,
and corresponding customer services, available interfaces on panels, matching
optical modules, and client-side ODUk cross connection.

When the QSFP+ PSM4 and MPO-LC branch optical fiber jumper are used on
interface 17 on the front panel, it supports being fanned out into four 10 Gbit/s Any
service SFP+ interfaces (numbering 19 to 22).

The iTN8600-I-XT4D does not support hybrid usage of one DC power supply and
one AC power supply.
Table 1-2 Client-side service modes
Mode
Client-side
service
Panel interface
Optical module
encapsulation type
Client-side
ODUk cross
connection
100GE
100GE
17–18
QSFP28
Not supported
OTU4
OTU4
17–18
QSFP28
Supported
40GE
40GE
17–18
QSFP+
Not supported
16G FC
5–16
SFP+(it needs to
supports 16G FC, up
to 6 ways)
10G Any
5–16
SFP+
Mappe
r
16G FC
1–8
SFP+(it needs to
supports 16G FC, up
to 6 ways)
Not supported
9–16
SFP+(it needs to
supports 16G FC, up
to 6 ways)
10G Any
1–16
SFP+
17 (fanned out into
4 interfaces
numbering 19–22)
QSFP+ PSM4
