Raisecom
iTN8600-I (A) Product Description
5 Appendix
Raisecom Proprietary and Confidential
Copyright © Raisecom Technology Co., Ltd.
40
44.6 Gbit/s (MPO)
Table 5-10 Parameter of the UQSP module (44.6 Gbit/s, MPO)
Model
Tx
wavele
ngth
(nm)
Rx
wavelengt
h (nm)
Tx
optical
power
(dBm)
Overl
oad
(dBm)
Extinc
tion
ratio
(dB)
Rx
sensitivit
y (dBm)
Mo
de
Transmi
ssion
distance
(km)
UQSP-
40G/PSM4
1310
12601355
-7 to 1.5
(single
channel)
> 0.5
> 3.5
< -11
SM
0.002 to
10
5.1.5 UQP
Table 5-11 Parameters of the UQP module (103.1 Gbit/s and 111.8 Gbit/s, LC/PC, dual-fiber
bidirectional, UQP-100G/LR4 compatible with 100GE and OTU4, with other models supporting
100GE only)
Mode
l
Tx
wavelen
gth (nm)
Rx
wavelength
(nm)
Tx optical
power
(dBm)
Overl
oad
(dBm)
Extinctio
n ratio
(dB)
Rx
sensitivity
(dBm)
Mo
de
Trans
missio
n
distan
ce
(km)
UQP-
100G/
SR4
850
840860
-8.4 to 2.4
> 3.4
> 2
< -9
M
M
0.0005
to 0.1
UQP-
100G/
CW4
1271
1291
1311
1331
1264.5
1277.5
1284.5
1297.5
1304.5
1317.5
1324.5
1337.5
Single
channel: -
6.5 to 2.5
Total: < 8.5
> 3.5
> 3.5
< -10.0
SM
0.002
to 2
UQP-
100G/
LR4
1295.56
1300.05
1304.58
1309.14
1294.53
1296.59
1299.02
1301.09
1303.54
1305.63
1308.09
1310.19
100GE
single
channel: -
4.3 to 4.5
OTU4
single
channel: -
0.6 to 4.0
100GE
total: < 10.5
OTU4 total:
< 10.0
> 5.5
100GE:
> 4
OTU4:
46.5
100GE: <
-8.6
OTU4: < -
8.4
SM
10
