Raisecom
iTN8600-I (A) Product Description
Raisecom Proprietary and Confidential
Copyright © Raisecom Technology Co., Ltd.
Insulation and voltage
resistance (wire)
Supported, indicated by D in the cable name, being 4 m by
default
Connecting DC power cable and connectors
In China, the DC-power-model iTN8605 is delivered with the DC power cable and 3-pin
connector. In other countries and regions, only 3-pin connector is provided, so you need to
make the DC power cable according to local standard and parameters in Table 5-18. Connect
the 3-pin connector to the DC power cable, as shown in Figure 5-10.
Connect the power cable according to the positive pole, negative pole, and ground
terminal on the panel. Connect the positive pole, negative pole, and ground end of
the power sourcing equipment to the positive pole (RTN), negative pole (-48 V), and
ground terminal of the DC power supply of the iTN8600-I respectively.
The conducting wire must be fully inserted into the connector.
Step 1 Use a wire stripper to strip the protective sheath at the end of the DC power cable, leaving 20-mm
conducting wire.
Step 2 Use the wire stripper to strip the external coat of the conducting wire, leaving 6.5-mm conductor.
Step 3 Insert the power cable into the 3-pin connector. Fasten the screw to fix the connector and DC
power cable.
