Raisecom MSG1200 User Manual

Raisecom
MSG1200 (A) User Manual
2 Product structure
Raisecom Technology Co., Ltd.
10
LED
Name
Color
Status
Description
PON
PON interface
status LED
(available for the
MSG1200-
/EPON/UPON
only)
Green
Green
The PON interface is registered.
Blinking
green
The PON interface is being
registered or fails.
Off
The PON interface is not
registered.
LOS
Optical signal
status LED
(available for the
MSG1200-
EPON/UPON only)
Red
Blinking
red
The Rx optical power of the
PON interface is lower than the
sensitivity of the optical
receiver.
Off
The Rx optical power of the
PON interface is normal.
Internet
Internet status LED
Green
Green
Internet configurations take
effect. The device can obtain the
IP address and DNS, as well as
access the Internet properly.
Off
Internet configurations do not
take effect. The device accesses
the Internet improperly.
WLAN
WLAN status LED
Green
Green
The WLAN connection is
established without service flow.
Blinking
green
The WLAN connection is
established with service flow.
Off
The WLAN connection is not
established.
FXS2–
FXS1
Voice status LED
Green
Green
The device has registered the
soft switch without service flow.
Blinking
green
Service flow is being
transmitted.
Off
The device is powered off or
fails to register the soft switch.
LAN4–
LAN1
LAN interface (1–
4) status LED
Green
Green
The link is reachable without
service flow.
Blinking
green
The link is reachable with
service flow.
Off
The link is unreachable or
blocked.
WPS
WPS status LED
Green/
Green
Registration succeeds and the
LED is lighted up for 5min.
