Raven RS1 - Roadway Homologation and Certifications

016-4010-001 Rev. J 105
SLINGSHOT
FIGURE 34. Diagnostic Trouble Codes Page
NOTE: In Figure 34 on page 105 above, inactive DTC is 2.01 and the DTC summary is “No Ethernet
Connection.”
•Pressing the Info button displays the complete description of the highlighted active DTC.
•Pressing Clear deletes the inactive DTCs from the Inactive DTC error log.
Diagnostic Trouble
Code (DTC)
DTC Summary
