CHAPTER 2
INTRODUCTION
Thank you for purchasing the RS1™ system.
The instructions in this manual are designed to assist in the proper calibration and operation of the RS1 system
when used with the Viper 4 or CR7 series field computers.
NOTE: Installation of the RS1 system must be completed before calibrating the system. Refer to the machine-
specific RS1 Installation Manual for assistance with installation of the RS1 system.
The Raven field computer must be calibrated specifically for the equipment before being used to
operate the RS1 system. Refer to the Operation Manual for the field computer used to operate the
RS1 system.
Installation and Operation Manuals for Raven systems can be downloaded from the Raven website:
https://portal.ravenprecision.com/
SYSTEM SPECIFICATIONS
RS1 ELECTRICAL RATING
The specifications below are specific to the RS1 system:
INSTALLATION BEST PRACTICES
Current Rating Voltage Range
6 Amps 8 - 24 Volts
WARNING
Carefully read and follow all safety requirements
and precautions contained in this manual and the
machine-specific Installation Manual. Failure to
follow safety instructions may lead to equipment
damage, personal injury, or death.
