MenuItemRadarscannerDescriptionOptions

FTC•(NonHD)DigitalRadomeTheFTC(FastTimeConstant)settings

enablesyoutoremoveareasofclutter

atadistancefromyourvessel.It

alsohelpsyoutodistinguishbetween

twoverycloseechoesonthesame

bearing,whichmayotherwisemerge

andappearasoneecho.

•Auto

•Manual(0%to100%)

Rain•AllTheradarscannerdetectsechoes

fromrainorsnow.Theseechoes

appearonscreenascountlesssmall

echoescontinuouslychangingsize,

intensityandposition.Turningtherain

clutterfunctionOnsuppressesthebulk

effectofrainreturnsfromaroundyour

vessel,makingiteasiertorecognize

otherobjects.Youcanadjustthe

intensityofthissettingbetween0and

100%.

•On—enablestheRainfunction

andallowsyoutoadjustthesetting

between0and100%.

•Off—disablestheRainfunction.

Thisisthedefault.

Radarapplication

249
