Chapter 1: Preparation for installation 5
Chapter 1: Preparation for installation
1.1 General information
Contents of this pack
The C-Series (C70, C80 or C120) Display pack contains the following items:
Note:
To prevent damage, unpack the display carefully. Save the carton and packing, in case
the unit has to be returned for service.
Item Quantity
Part No.
C-70 C-80 C-120
C-Series Display 1 5566-001 5579-001 5579-003
Display Bezel 1 R08001 R08002 R08046
Trunnion Bracket 1 R08020 R08020 R08020
Trunnion Bracket knobs 2 W145 W145 W145
Panel mounting seal 1 R08015 R08026 R08037
Sun cover 1 R08019 R08019 R08019
Trim ring 1 R08021 R08021 R08021
Power Cable (1.5m) 1 R08003 R08003 R08003
NMEA cable (1.5m) 1 R08004 R08004 R08004
SeaTalk/Alarm out cable (2m) 1 R08050 R08050 R08050
No.10 x 3/4” Pozi-drive screws for
Trunnion Bracket
3 21238 21238 -
M4 x 8 Pozi head 4 21284 21284 21284
M4 x 30 Pozi head 4 21339 21339 21339
Scotchlock connectors 3 07453 07453 -
Documentation pack including:
Reference Manual
Installation Manual
Operating Guide
Flush Mount Template
1
1
1
1
84169_6
87020-3.book Page 5 Tuesday, March 7, 2006 11:02 AM
