Chapter 1: Preparation for installation 7
C120 Display
Accessories and spares
Raymarine accessories and parts can be obtained from your authorized Raymarine
dealer. However, if you are in need of an item not available from the retailer or you are
uncertain what item to choose for your Display, please contact Raymarine direct (see
page 46
). Alternatively, please refer to our website: www.raymarine.com
RANGE
CANCELOK
PAGE
ACTIVE
WPTS
MOB
MENU
DATA
IN
OUT
357 mm (14 in)
385 mm (15.15 in)
9.5 mm
(0.375 in)
87.9 mm
(3.46 in)
220 mm (8.66 in)
plug clearance
267 mm (10.5 in)
276.66 mm (10.9 in)
D6611-1
