ii C-Series Displays Installation Manual
CAUTION: Radar Scanners, Cables & Installation
Information on radar scanners, cables and their installation contained in
this handbook supersedes that contained in the Pathfinder Radar
Scanner Handbook, Document No. 81154_8, dated 12th January 2005.
CAUTION: Bezel Installation
After installing the front bezel, check that all buttons and softkeys have
passed through the bezel completely and are free to operate correctly.
CAUTION: Global Positioning System Antenna
Do not connect or disconnect the GPS antenna from the display unit
whilst power is switched on. Doing this may result in irreparable damage
CAUTION: Water Ingress
To prevent the ingress of water and damage to the display, ensure that
the chart card door is firmly closed. This can be confirmed by an audible
click.
CAUTION: Connections into the display
Ensure power is switched off prior to connecting or removing any cables
into the rear of the display. Failure to do so can cause irreparable
damage.
CAUTION: CompactFlash Card Installation
When installing CompactFlash cards ensure that the card is being fitted
the correct way round. DO NOT try and force the card into position as this
may result in irreparable damage to the card.
CAUTION: CompactFlash Cards
Removing the CompactFlash card whilst information is being written to
it may cause damage to the card and loss of all data. A warning on the
display indicates when writing is in progress.
CAUTION: Chart and CompactFlash card damage
DO NOT use a metallic instrument such as a screwdriver or pliers to help
you remove a card, as doing this can cause irreparable damage to the
card and/or display unit.
EMC Conformance
All Raymarine equipment and accessories are designed to the best industry standards
for use in the recreational marine environment.
The design and manufacture of Raymarine equipment and accessories conform to the
appropriate Electromagnetic Compatibility (EMC) standards, but correct installation is
required to ensure that performance is not compromised.
87020-3.book Page ii Tuesday, March 7, 2006 11:02 AM
