6.Inserttheunitintothemountingtray
,ensuringthetabsintheMountingtrayareslottedintothe
groovesaroundtheedgeoftheunit.
Important:
TheunitmustbemountedwiththeLED‘arrow’inparallelalignmentwiththelongitudinalaxis
(centerline)ofthevesselandbepointingtowardsthevessel’
sbow.
7
.PlacetheMountingtrimovertheunitslightlyoffset,andthentwisttheMountingtrimclockwise
untilitlocksintoposition.
Installation37
