12.5LEDindications—EV-2
LED
colorLEDcodeS tatusActionrequired
Solidgreen
Normal
operation.
•None(normalpower
uptak
es<1minute.)
L
ongflash
greenon(x1),
longflashoff.
Cyclerepeats
after2seconds.
Unitis
initializing;
nopilotor
compass
functions
currently
available.
•None(normalpower
uptakes<1minute.)
Longflash
greenon(x2),
longflashoff.
Cyclerepeats
after8seconds.
NoDeviceNet
connection.
•Ensurenetworkis
powered.
•Ensurenetwork
cableand
connectionsare
secureandfree
fromdamage.
•Ifproblempersists
contactRaymarine
technicalsupport.
Shortflash
greenon(x7),
longflashoff.
Cyclerepeats
after9seconds.
DeviceNet
connectedbut
notreceiving
data.
•Ifproblempersists
contactRaymarine
technicalsupport.
Shortflashred
on(x2),long
flashoff.Cycle
repeatsafter4
seconds.
NoSeaTalk
ng
connection.
•Ensurenetworkis
powered.
•Ensurenetwork
cableand
connectionsare
secureandfree
fromdamage.
•Ifproblempersists
contactRaymarine
technicalsupport.
Shortflashred
on(x7),long
flashoff.Cycle
repeatsafter9
seconds.
SeaTalk
ng
connectedbut
notreceiving
data.
•Ifproblempersists
contactRaymarine
technicalsupport.
