Raymarine Evolution EV-2 - Connections Overview - EV-1 and EV-2; Connecting Seatalkng Cables; Connections Overview - EV-1 and

9
.2Connectionsoverview—EV-1andEV-2
1.Sea Talkng®
2.DeviceNet
Important:
TheDeviceNetportisforusewiththeEV-2only .DoNOTconnectthisportontheEV-1unit.
ConnectingSea Talkng®cables
1.R otateyourproduct’sSeaTalkng®connectorlockingcollarcounterclockwise,sothatthe
connectorisintheunlockedposition.
2.Ensurethecable’sconnectoriscorrectlyoriented(groovepointingup).
3.Fullyinsertthecableconnector..
4.Rotatethelockingcollarclockwise(2clicks)untilitisinthelockedposition.
EV -2connections45
