Raymarine Evolution EV-2 - Alarms

12.4Alarms
Alarmsareraisedbytheautopilotsystemtoalertyoutomechanicalandelectricalconditions
requiringyourattention.
TheEvolutioncomponentstransmitalarmalertsontheSea
Talkng®networkfordisplayonautopilot
controllersandMFDs,alongwithanaudiblealert.TheEvolutioncomponentsstopraisinganalarm
whenthealarmconditionceasesorthealarmisacknowledgedontheautopilotcontrollerorMFD.If
thealarmissafety-criticalitwillberaisedagainafteratimeddelay.
Unlessotherwisestatedinthetablebelow,youshouldrespondtoalarmsbyselecting
OKor
AcknowledgeonyourautopilotcontrollerorMFD .
AlarmMessageP ossiblecausesSolution
OFFCOURSEA utopilothasdeviatedfrom
plannedcourse.
Checkyourvesselposition
andifnecessarytakemanual
controltosteerthevesselback
oncourse.
WINDSHIFT
A utopilotisunabletomaintain
navigationtothecurrentwind
angle.
L OWBATTERY
Powersupplyvoltagehas
droppedbelowacceptable
limits.Causedbylowbattery
voltageorvoltagedropatthe
ACUunit(EV-1systemsonly),
duetopoorconnectionsor
inadequatewiring.
Acknowledgethealarm
andthenstarttheengine
torechargethebattery.If
problempersists,checkwiring
connectionsandthatthe
qualityandgaugeofwiringis
adequateforthecurrentdraw
ofthedriveunit.
LARGEXTE
L argecross-trackerror.The
autopilothasdeviatedmore
thanexpectedfromaplanned
course.
Checkyourvesselposition
andifnecessarytakemanual
controltosteerthevesselback
oncourse.
CUDISCONNECTED
Theautopilotcontrolheadhas
beendisconnected.
•Checkthephysicalcables
andconnectionsbetween
theautopilotcontrolhead
andtheSea
Talkng®system.
AlsobetweentheEV-1/EV-2
andtheSeaTalk
ng
system.
•Iftheautopilotcontrolhead
isconnectedviaaSeaTalk®
toSea Talkng®converter,
checktheconverterisusing
thelatestsoftwareversion.
W AYPOINTADVANCE
Theautopilothassteeredthe
vesseltothecurrentwaypoint.
Acknowledgetheturntothe
nextwaypoint.
ROUTECOMPLETE
Y ourvesselhasarrivedatthe
endofthecurrentroute.
Noactionrequired.
NOD ATA
•TheautopilotisinWind
Vanemodeandhasnot
receivedwindangledatafor
32seconds.
•TheautopilotisinTrack
modeandisnotreceiving
navigationdata,ortherudder
anglesensorisreceivinga
low-strengthsignal.This
Checktheconnectionstothe
windtransducer,multifunction
display,andautopilotcontrol
head(asappropriate).
S ystemchecksandtroubleshooting
67
