Raymarine RVM-100 User Manual

3.
1Productoverview
TheRVM-100transducerisatransommountRealVision™Max3Dtransducer,
withplasticconstruction.
InconjunctionwithaR ealVision™Max3Dcompatiblemultifunctiondisplayor
sonarmodule,theRVM-100transducerproducesrealistic3Drepresentations
oftheobjectsbelowyourvessel,tohelpyouidentifyunderwaterstructures
andlocatefish.
RealVision™Max3Dtransducersbenefitfromimprovedpingratesandtighter
beamwidths,resultinginsharpersonarimages,detailedwrecks,anddistinct
fishtargets.RealVision™Max3Dtransducersalsoprovidehighercontrast
colorpalettesforaccentuatingtargets,allowingfishtargetstostandout
fromthewatercolumnnoise.
Thetransducerhasthefollowingsonarchannels:
•4sonarchannels,combinedinasingletransducer:
–RealVision™Max3D
–SideVision™
–DownVision™
–ConicalHighCHIRP/LowCHIRP600W/200kHz
•RealVision™Max3Dtransducersincludeabuilt-inAHRS(Attitudeand
HeadingReferenceSystem)sensorthathelpsstabilize3Dimaging
automatically,bycompensatingforvesselmotion.
•Thetransducerprovideseasytransommounting,andcanalsobemounted
onastep,trollingmotororonajackplatewhenusingtherelevant
accessories:
–Stepmountbracket(partnumberA80479).
–Trollingmotormount(partnumber:A80483).
–Jackplatemount(partnumberA80480).
–Jackplatespacerkit(partnumberA80482).
•8m(26.2ft)fittedcable.
RealVision™Max3Doverview
RealVision™Max3Dtransducersofferthefollowingrangeofimprovements
overRealVision™3Dtransducers:
•Improvedpingratesandtighterbeamwidths,resultinginsharpersonar
images,detailedwrecks,anddistinctfishtargets.
•HigherresolutionDownVisionandSideVisionimaging,combinedwith
highercontrastcolorpalettes—makingiteasiertoidentifystructure,and
allowingfishtargetstostandoutfromthewatercolumnnoise.
•Moreaccuratetargetlocationcapability,makingiteasiertopinpointthe
positionofawreckorsetupadrift.
•New600WHighCHIRPfrequencyprovidesdeepertraditionalsonar
rangeandstrongertargetreturns.
RealVision™3DMaxscreenexample
Productandsystemoverview
13

Raymarine RVM-100 Specifications

General

Brand	Raymarine
Model	RVM-100
Category	Transducer
Language	English
