.2Connectingthetransducer
ThetransducercanbeconnecteddirectlytotheRealVision™connectoron
therearofAxiom™2ProMFDs,ortheRVM1600sonarmodule.
Aright-angledconnectoradaptorcable(A80515)isavailableforinstallations
wherespacebehindtheMFDislimited.
•A—MFD/sonarmoduleconnector .
•B—Orientationindicator.
1.EnsurethepowersupplytoyourMFD/sonarmoduleisswitchedoff.
2.Ensuringcorrectorientation,pushtheconnectorfullyintotheRealVision
connectionofyourMFD/sonarmodule.
Thecableconnectorincludesamarkingtoindicatethetopofthe
connector.
3.Turnthelockingcollarclockwisetosecuretheconnection.
9.3RealVisiontransducerextensioncables
Y ourtransducerissuppliedwithafittedcable,forsomeinstallations
(includingallsplit-pairtransducerinstallations)itmaybenecessarytoextend
thelengthofthetransducercable.
Note:
•Forbestperformance
,cablerunsshouldbekepttoaminimum.
•OnlyuseRaymarine®transducerextensioncables.
Raymarine®offershefollowingoptionalextensioncablesareavailable:
•RealVision™transducerextensioncable3m(9.8ft)(partnumberA80475)
•RealVision™transducerextensioncable5m(16.4ft)(partnumberA80476)
•RealVision™transducerextensioncable8m(26.2ft)(partnumberA80477)
Splitpairtransducers:Extensioncablesfittedbetweenthetransducerand
the‘Y’cablemustbefittedinequallengthpairs(i.e.:eachtransducer’sfinal
cablelengthmustbethesame).
9.4Maximumtransducercablelength
ThemaximumlengthofcablebetweenaRealVision™Max3Dtransducerand
aMFD/sonarmodule(includingthetransducer’scaptivecable)mustNOT
exceed18m(59ft).Cablelengthsgreaterthanthismaycausedamageto
theRealVision™Max3DtransducerandMFD/sonarmodule.
