1Transducerdimensions
Item
Dimension
A
76.00mm(3.00in)
B
120 .00mm(4.72in)
C
256.6mm(10.10in)
D
70 .00mm(2.76in)
E
48.5mm(1.91in)
F
26.00mm(1.01in)
G
35.00mm(1.38in)
H
4.50mm(0 .18in)
I
13.80mm(0.54in)
J
30 .00mm(1.18in)
K
8m(26.2ft)fittedcable
5.2R
ealVisiontransducercableconnector
dimensions
Thedimensionsofthetransducercableandcableconnectorareshown
below.
Cableconnectordimensions
Item
Dimension
A
32.00mm(1.26in)
B
25.00mm(1.00in)
C
96.00mm(3.80in)
D
Cablelength:
•Single(All-in-one)transducerfittedcablelength:8m(26.2
ft).
•Splitpairtransducerfittedcablelength:2m(6.5ft).
E
ThisdimensionisdependentonyourMFDvariant.Referto
yourMFDinstallationinstructions.
F
ThisdimensionisdependentonyourMFDvariant.Referto
yourMFDinstallationinstructions.
G
35.00mm(1.40in)
18
