Sonarrange
Thesonarrangeistheeffectivedepthordistancethatthetransducercan
operateto
,inoptimumweatherconditions.
ThefollowingrangesapplytoRealVision™Max3Dsonarchannels:
Note:
Thelistedsonarchannelrangesareindicativeonly
,andaresubjectto
changedependingupontheconnectedtransducer.
Sonarchannel
R ange
CHIRPsonar:
0 .6m(2ft)to366m(1,200ft)
Down Vision™:
0.6m(2ft)to183m(600ft)
SideVision™:
0.6m(2ft)to91m(300ft)
R ealVision™Max3D:
0.6M(2ft)to91m(300ft)
Compatiblesonarmodulesanddisplays
T ransducersmustbeconnectedtoacompatiblesonarmoduletointerpret
andtransmitthesonarimagetoadisplayscreen.Thesonarmodulemaybe
externalorinternal(built-in)tothedisplay.
Y ourtransduceriscompatiblewiththefollowingsonarmodules:
•Axiom™2ProrangeofMFDs,whichincludeacompatibleinternalsonar
module.
•RVM1600RealVision™Max3Dexternalsonarmodule.
Note:
ThetransducerisNO TcompatiblewiththeRVX1000RealVision™3D
externalsonarmodule,ortheinternalsonarmodulesbuilt-intoAxiom™,
Axiom™+andAxiom™ProMFDs.
R
ealVisiontransducerextensioncables
Y ourtransducerissuppliedwithafittedcable,forsomeinstallations
(includingallsplit-pairtransducerinstallations)itmaybenecessarytoextend
thelengthofthetransducercable.
Note:
•Forbestperformance
,cablerunsshouldbekepttoaminimum.
•OnlyuseRaymarine®transducerextensioncables.
Raymarine®offershefollowingoptionalextensioncablesareavailable:
•RealVision™transducerextensioncable3m(9.8ft)(partnumberA80475)
•RealVision™transducerextensioncable5m(16.4ft)(partnumberA80476)
•RealVision™transducerextensioncable8m(26.2ft)(partnumberA80477)
Splitpairtransducers:Extensioncablesfittedbetweenthetransducerand
the‘Y’cablemustbefittedinequallengthpairs(i.e.:eachtransducer’sfinal
cablelengthmustbethesame).
Warning:Maximumtransducercablelength
ThemaximumlengthofcablebetweenaRealVision™Max
3DtransducerandaMFD/sonarmodule(includingthe
transducer’scaptivecable)mustNOTexceed18m(59ft).
Cablelengthsgreaterthanthismaycausedamagetothe
RealVision™Max3DtransducerandMFD/sonarmodule.
14
